Myavr board MK1 lpt plus, assembly kit


Your entrance into microcontroller programming!
myAVR Board MK1 LPT PLUS LCD, assembly kit
myAVR Board MK1 LPT PLUS, Bausatz
with ATMEL microcontroller ATmega8, SP 12 compatible programmer and high-quality LCD kit - LCD with background lighting!
Attention: you have to assemble the board by yourself.
* inclusive low power microcontroller
* all necessary electronic components and printed circuit board
* with invoice and Email-support
* designed after didactic principles
* with myAVR LCD Add-On as assembly kit!
* LCD with contrast regulator and
* programmable brightness control
myAVR Board MK1 LPT, assembly kit:
* 1 printed circuit board myAVR Board MK1 (unequipped, pre drilled, tin-plated, industrial quality)
* 1 microcontroller ATmega8L 8PI
* 1 voltage regulator 6V, 7806
* 2 capacitor 33pF for quartz
* 2 potentiometer 47 kOhm with shaft
* 2 Pin header 20 way, female, straight
* 1 Pin header 20 way, female, right angle
* LCD with 16 character, 2 lines
* pin header 20 way, female, right angle
* pin header 20 way, male, right angle
* pin header 20 way, female, straight
* potentiometer (for contrast)
* resistors (brightness control over PWM)
myAVR Board MK1 LPT, Bausatz (Bauteile)
Software and documents on CD. More available in internet:
