Atten ADS1102 digital storage oscilloscope 100MHZ
ATTEN ADS1102 DIGITAL STORAGE OSCILLOSCOPE 100MHz
Link to Atten website http:// .cn/english/index.html
The Common Specifications Of All ADS1000 Series Products
12 divides full screen display
Edge, Pulse, Video, Slope, Alternative, Delay
Vpp, Vmax, Vmin, Vamp, Vtop, Vbase, Vavg, Mean, Vrms, Crms, ROVShoot, FOVShoot, RPREShoot, FPREShoot, Freq, Period, Rise time, Fall Time, +Width, -Width, +Duty, - Duty, BWid, Phase, FRR, FRF, FFR, FFF, LRR, LRF, LFR, LFF
Window: Hanning, Hamming, Blackman, Rectangular
Support the sampling rate : 5KSa/s 200MSa/s (in a 1-2-5 sequence)
Main, Window, Window Zoom, Roll, X-Y
2Sec, 5Sec, 10Sec, 20Sec, Infinite
Simplified Chinese, Traditional Chinese, English, Arabic, French, German, Russian, Spanish, Portuguese, Japanese, Korean
100-240VAC 47HZ-440HZ 50VA Max
305mm x 154mm x133mm,about2.3kg (4 With Packing and Accessories)
(1:1 10:1)Problex2, EasyScope Computer Software System, Power Cord, USB Cable, User Manual, EasyDsoLib Software Package,
USB Host: Support USB flash drive storage
USB Device: Support PictBridge compatible printers and PC Remote control
GPIB Communication Module, Serial Interface Communication Module, Pass/Fail Interface Module
