Siemens fs-100 fs-rd
The Model FS-RD Remote Display is used for annunciating
system events remotely from the fire alarm control
panel on the FireSeeker FS-100 system. A red version
called the FS-RD-R is also available. The FS-RD will
mimic the system status LEDs and the 80-character
event message found on the main system panel.
The 4 x 20 LCD backlit display will illuminate upon
receiving any event from the system, or upon
pressing any button on the FS-RD.
System Acknowledge, Silence and Reset Capabilities
are available on the FS-RD. The control functions must
be enabled using the integral keyswitch. Up to sixteen
supervised FS-RD annunciators can be used simultaneously
on the FireSeeker FS-100 system.
Mounting is accomplished using a standard 6 gang 2"
deep electrical box. The FS-RD requires a 2-wire data
connection from the RS-485 port on the FS-100, as
well as 24 VDC power. Maximum wire loop resistance
4 x 20 Character Backlit Display
Integral System Control Capabilities
Integral System Maintenance access
Remote LCD Annunciator for the FireSeeker FS-100 System
