Breadboard power supply dual outputs 3.3V, 5V assembled
Dual Output Fixed Voltage Power Supply for Breadboard prototyping
* Dual LDO Voltage regulators (LD1117xx series)
* Low dropout voltage (1V typ.)
* Internal current and thermal limit
* Fixed output voltages of 3.3vdc and 5.0vdc
* Built in input reverse voltage protection (Diode)
* 500mA, (1A trip) polyfuse for over current protection
* Provides a clean 100ma source of power, heat dissipated by regulators Dependant on load and input supply. Regulators may get hot, use caution.
* Electrolytic capacitors for ripple rejection
* Input voltage: 7 to 13.2VDC,
* Standard 2.1mm ID, 5.5mm OD Barrel Jack
* LED to indicate power is on
* Fits standard breadboards and supplies 5vdc & ground to the top rail, and 3.3vdc & ground to the bottom rails.
* Arrives fully assembled and tested.
This dual output power supply is great for many of your prototyping needs!
More and more projects require both 5vdc and 3.3vdc - this handy power supply provides fixed, regulated outputs of both. Simply plug this supply into your breadboard, and get a clean regulated supply of 5.0vdc to the top bus, and 3.3vdc to the bottom. Ground is supplied to the second line on each bus for convenience.
This power supply will work with DC input voltages in the range of 7 to 13.2vdc.
This item is fully assembled and tested.
