Lodestar l 1 ton hoist & 20' electric trolley i-beam
(1) 1 TON CM LODESTAR-L ELECTRIC CHAIN HOIST
WITH SERIES 635 LOW HEAD ROOM TROLLEY
AND 20 FOOT 1 TON ELECTRIC TROLLEY I-BEAM
These are electric trolley beams that maintain constant power to the hoist. These beams when installed will travel when hooked to a control power station.
More are available, so if you want to make a package deal let us know.
Product information is available below the picks.
Photobucket Photobucket Photobucket Photobucket Photobucket Photobucket Photobucket Photobucket Photobucket Photobucket Photobucket Photobucket Photobucket Photobucket
The CM LODESTAR-L electric chain hoist is completely sealed rated NEMA 4 for:
* Impact-resistant control station for industrial durability
* Snap action contacts for positive control and reduced down time caused by electrical arcing
* internal strain relief made from high strength aircraft cable prevents control cable from being pulled out of the hoist or control station
Simple installation and service
Accessible design makes the CM LODESTAR-L hoist the easiest electric chain hoist to install and service, featuring:
* Completely identified wiring for fast and simple connections
* Easy access to working parts for fast trouble shooting and repair
* reduced maintenance for less down time and greater productivity
* Three phase single speed offers simple voltage change for adaptation for different applications
* Easy voltage change makes this model usable on either 230 or 240 volts-eight quick connect terminals are transferred in just seconds
Heavy-duty hoist motor with regenerative braking
The CM LODESTAR-L electric chain hoist motor is designed for industrial applications. Integral motor design includes:
* Meets or exceeds HMI (hoist Manufacturing Institute) duty cycle rating for heavy duty service H4
* Provides efficiency and cooler operations for longer hoist life
* Gives Substantially height duty cycle for greater productivity with your electric chain hoist
* Uses effient regenerative braking that avoids heat generation or power reduction in power train.
Cast Aluminum Alloy housing and covers
The CM LODESTAR-L electric chain hoist has an integral frame and housing design that provides lightweight low profile:
* Minimum headroom maximum lift
* Better heat dissipation from motor/brake and gear train
The CM LODESTAR-L chain guides completely surround the lift wheel to:
* Maintain proper load chain lift
* Jam resistant chain feed for reduced down time and maintenance
The CM LODESTAR-L Protector takes the worry out of hoist operation through:
* Positive over load protection that prevents lifting dangerous loads
* Extra security in the event of limit switch misalignment or misphasing of power leads
Machined alloy steel heat treated lift wheel
The CM LODESTAR-L chain hoist lift wheel is lift wheel machined and heat treated for additional strength and durability
* Reduced wear for longer liftwheel, chain guide and chain life
Lifetime lubricated machined and heat treated gears
The CM LODESTAR-L electric chain hoist has a simple spur and helical triple reduction gear system that operates in grease and provides:
* Superior service and maintenance characteristics
* Smooth operation and reduced wear
* No oil contamination of load or work area
* No troublesome seals to leak or replace
* Lifetime Lubricated ball bearings support load bearing, rotating shafts
Disk type electric hoist brake
The CM LODESTAR-L electric chain hoist's heavy-duty electric hoist brake provides positive load control. performance features:
* Securely holds load, even in event of power or phase failure
* Eliminates heat build up found in mechanical type braking system
* Requires little maintenance and few adjustments
Drop forged, heat treated hooks and special lifting chain
Superior quality overhead lifting chain, plus forged suspension and load hooks provide:
* Higher strength for lifting confidence
* Greater durability for longer life
* Hoist alloy lift chain for maximum strength and wear
