> Marwin 6-axis cnc traveling gantry bridge mill
Marwin 6-axis cnc traveling gantry bridge mill
Marwin 6-Axis CNC Traveling Gantry Bridge Mill
Allen Bradley 8600 7-Axis CNC Control
32 Station Automatic Tool Changer
Y-Axis Travel .......................... 143.35"
X-Axis Travel ........................... 512.50"
Z-Axis Travel ........................... 28.4"
W-Axis Travel ......................... 4"
A-Axis ................................... +/- 46 Degrees
B-Axis ................................... +/- 46 Degrees
Table Size .............................. 92" x 534"
Distance Between Housings .... 98.42"
Height Under Rail .................... 27"
Spindle Speeds, 3-Ranges ...... 200-12,000 RPM
Spndle Taper .......................... #45
Bed Width ............................. 101"
Length of Each Bed Section .... 144"
X-Axis ................................... 0 to 788 IPM
Y-Axis .................................. 0 to 590 IPM
Z-Axis ................................... 0 to 394 IPM
W-Axis ................................. 0 to 200 IPM
A & B Axes ........................... 0 to 600 Deg/minute
Allen Bradley 8600 6-Axis CNC Control
Inductosyn Scales on W,A, and B Axes
Resolver Feed Back on X,Y, and Z Axes
FOB Our Philadelphia Warehouse!
