Yaesu ftm-10R transceiver + free mh-68A6J speaker mic
This is original Yaesu FTM-10R Dual band transceiver with FREE MH-68A6J original speaker mic. 100% new, factory packed and never been used.
FTM-10R has great new features to support outdoor motor sports activities. It is waterproof/dustproof front operation panel to support all-weather outdoor activity (meets the IP57 standard. Waterproof at 1m for 30 minutes and protection agains dust).
The high power RF output of the FTM-10R is produced by the heavy duty, high efficiency, RF POWER MOS FET amplifier. Powerful and reliable 2 m / 70 cm Band operation is guaranteed.
The FTM-10R has a completely independent AM/FM broadcast radio receiver, in addition to the amateur band receiver. You will enjoy broadcast band receiver coverage, and high quality operation on the 2 m / 70 cm bands at the same time.
Band Group Memory System - The versatile memory system uses up to 500 memory channels. Each memory channel can be labeled with an 8-digit alphanumeric tag. The memory channels may be recalled by a specific operating band, if desired.
The FTM-10R has a large 2 inch/50 mm, 1.5W speaker in the die-cast chassis and is equipped with a high power 8-watt audio amplifier, and a PA function for outdoor operation with the optional MLS-200-M10 speaker(s). A high quality 1.1 inch/28 mm speaker is built into the detachable front panel; you can operate it
Great new appearance! The keys and indicators are illuminated with very bright LEDs. The bright ocean blue negative type LCD display is easy on your eyes.
Super compact detachable front panel is ready to go with your motor vehicle!
The microphone and PTT button are built into the front panel. Detach the front panel with onetouch release when transmitting! The detachable front panel may be separated from the main chassis, and attached to a flat metal surface with the magnetic mounting bracket.
The simple hanger type bracket may be attached to the top or bottom. The front panel may be tilted up or down 20 degrees with an adaptor bracket. The basic installation kit is included. (With the adapter bracket, 10 ft / 3 m separation control cable, magnetic mount, and the one-touch release hanger bracket.)
A minimum number of key buttons on the front control panel, for safer operation during motor sports activities. The large multi-functional dial and durable keys are easy to operate even when wearing gloves.
Enjoy your FTM-10R outdoor with your motorcycle, SUV or RV anywhere! The commercial grade front panel meets the IP57 standard. (Waterproof at 3 feet (1 m) for 30 minutes, and protection against dust.) All connectors are waterproof.
Equipped with a high power 8-watt audio amplifier. Use the PA function with the optional, commercial
With the intercom feature, you can communicate with a fellow passenger. Hands-free intercom operation is available with the optional BluetoothR function.
AF Dual Monitor Function: Listen to your favorite AM or FM stereo broadcast station, and monitor an amateur band at the same time! External audio input is also available to connect your iPodR!
The main body of the FTM-10R is a solid die-cast aluminum sandwich structure. The high quality die-cast aluminum chassis doubles as the heat sink providing more than enough air-cooled ventilation for the power modules. The sandwich structure also provides far better resistance to vibration and shock than many conventional transceivers and radios.
The design shields against ignition noise and alternator whine for mobile operation!
The Smart Key feature: The "F" key on the control panel accesses the most frequently used functions.
AF Pre-Set Function - The audio volume bar appears on the LCD screen and shows an orange warning if the
volume is below a Preset level, preventing you from missing lower volume audio stations.
The Club Channel Monitor function permits your group to always monitor the designated user-defined frequency.
The message function can transmit alphanumeric messages (up to 20 messages/16 characters maximum) with a sender's ID. In an emergency the message can be communicated even in a noisy outdoor environments.
Wireless cloning allows transfer of memory information without any cable. (Note: The Wireless cloning function can only be performed by and between the FTM-10R transceivers. Other transceivers and
Includes an event timer stopwatch with an interval function to support many outdoor motor sports activities.
Tone control Band Up/Down key for easy operation. Simple key locking. Automatic Volume Control can adjust the speaker volume relative to a nearby noisy environment. Dimmer Display brightness control. Three transmit power levels are available: 50W (70 cm : 40W) / 20W /5W The VOX function includes automatic audio delay on transmit to ensure transmission of the start of your message. The Time-Out Timer (TOT) function can end a continuous transmission after a preset time. The Internet Connection Feature
can be used to access the Vertex Standard WiRES-II system. Various scanning features. DC input voltage display The Smart Search feature that will scan and load frequencies automatically where activity is found. The ARTS (Automatic Range Transponder System) feature which provides audio and/or visual
confirmation that another ARTS equipped station is within communication range.
- 1x Operating Manual (English)
