Used red-d-arc 3+2 welder cc/cv stick, mig, tig 460/575


2,000 Watts AC Auxiliary Power
Available in 4Pak and 6Pak Configurations
Built to Red-D-Arc Extreme-Duty Specifications
Arc Force, Hot Start, Continuous Output Control
Full Remote Control Capabilities
Outstanding arc characteristics on both constant current and constant voltage processes in a rugged, compact design. Includes MS-style connections for 115V wirefeeders and 3-pin remote controls.
Multiprocess Welders and Paks - Specifications
DC Amperage Range: 20 A at 20 V - 350 A at 34 V
Rated CC Output: 350 A at 34 VDC, 20% duty cycle
250 A at 30 VDC, 60% duty cycle
180 A at 27.5 VDC, 100% duty cycle
Three-Phase Rated Input Current at 250 A, 30 VDC, 60% duty cycle:
21.5 amps at 480 volts, 17 amps at 600 volts
Weight (including frame): 322 lb (146.1 kg)
H: 22.375" (568 mm) W: 21.25" (540 mm) L: 31.5" (800 mm)
Available Options and Accessories
Three-wheeled shop-type undercarriage, LN25 wirefeeder, RC1 remote control, 115 VAC constant speed wirefeeders and spool guns, 4Pak and 6Pak multioperator systems
This machine is manufactured by Red-D-Arc for use in industrial applications. It is a transformer based welder that operates on 460/575/600 Volt 3 Phase Power. It has been tested, calibrated, and is in perfect working order backed by a 30 day warranty.
