Lathe manuals (leblonde, sheldon, houdaille++): cd 914P
LEBLOND MACHINE TOOL COMPANY MODEL 17/28" REG
LEBLOND MACHINE TOOL COMPANY MODEL 17" REGAL
SHELDON MACHINE CO. INC., MODEL XL
STANDARD-MODERN TOOL SERIES 2,000 MODEL 11 INCH
LATHE, ENGINE TOOLROOM MODEL 1530
LATHE, ENGINE BENCH TYPE 12" HOUDAILLE INDUSTRIES, INC.
LATHE, ENGINE: 9-INCH SWING MODEL CL 670Z (SOUTH BEND LATHE)
and more (please see complete table of contents below)
20 documents with 914 pages of various technical manuals with diagrams and illustrations. Please see complete description of all the files on this CD below.
1. TECHNICAL MANUAL - OPERATOR S MANUAL - LATHE, ENGINE,
FLOOR MOUNTED, SLIDING BED GAP, 17 TO 28 IN. RATED SWING, 50 IN. OPEN AND 30 IN.
CLOSED BETWEEN CENTERS, 5-HP, 208-440-V, 3-PH, 60-C (LEBLOND MACHINE TOOL
COMPANY MODEL 17/28" REGAL) (3(***)-725-3508) AND LATHE, ENGINE, FLOOR MOUNTED,
PLAIN BED GAP, 17 TO 26 IN. RATED SWING, 30 IN. BETWEEN CENTERS, 3-HP, 208-416-V,
3-PH, 50/60-C (LEBLOND MACHINE TOOL COMPANY MODEL 17" REGAL) (3(***)-828-3714) (97
2. TECHNICAL MANUAL - ORGANIZATIONAL MAINTENANCE
MANUAL - LATHE, ENGINE, BENCH MOUNTED, SOLID BED TYPE, 10-INCH SWING, NO. 2
MORSE TAPER CENTER, 1-3/8 SPINDLE HOLE, 110-VOLTS, 60-CYCLE, SINGLE PHASE
3/4-HORSEPOWER, W/ARMY DWG NO. 7550151 BENCH (SHELDON MACHINE CO. INC.,
MODEL XL) (3(***)-517-0955) (39 pages)
3. TECHNICAL MANUAL - ORGANIZATIONAL MAINTENANCE
MANUAL - LATHE, ENGINE, BENCH MOUNTED, SOLID BED TYPE, 10 INCH SWING, NO. 2
MORSE TAPER CENTER, 1-3/8 SPINDLE HOLE, 110-VOLTS, 60 CYCLE, SINGLE PHASE
3/4-HORSEPOWER, W/ARMY DWG NO. 7550151 BENCH (STANDARD-MODERN TOOL SERIES
2,000 MODEL 11 INCH) (3(***)-517-0955) (38 pages)
4. TECHNICAL MANUAL - OPERATOR S, ORGANIZATIONAL,
DIRECT SUPPORT AND GENERAL SUPPORT MAINTENANCE MANUAL INCLUDING REPAIR
PARTS LIST FOR LATHE, ENGINE TOOLROOM MODEL 1530 (3416-00-517-1051) (51 pages)
5. TECHNICAL MANUAL - OPERATOR S, ORGANIZATIONAL,
PARTS LIST FOR LATHE, ENGINE BENCH TYPE 12" HOUDAILLE INDUSTRIES, INC.
(POWERMATIC DIVISION) (NSN 3416-00-449-7188) (72 pages)
6. TECHNICAL MANUAL - OPERATOR, ORGANIZATIONAL, DIRECT
SUPPORT AND GENERAL SUPPORT MAINTENANCE MANUAL INCLUDING REPAIR PARTS
LIST FOR LATHE, ENGINE: 9-INCH SWING MODEL CL 670Z (SOUTH BEND LATHE)
7. TECHNICAL MANUAL - OPERATOR S, ORGANIZATIONAL,
PARTS LIST FOR LATHE, ENGINE MODEL 1754 (NSN) 3416-00-250-6550) STANDARD-MODERN
TOOL COMPANY, LIMITED (39 pages)
PARTS LIST FOR LATHE, ENGINE, FLOOR MOUNTED: 19-INCH SWING MODELS 17E5 AND
19E7 (LEBLOND INC.) (NSN 3416-00-252-7094) (83 pages)
PARTS LIST FOR LATHE, ENGINE MODEL B-40 (MC ILVANIE MACHINE WORKS) (NSN
10. TECHNICAL MANUAL - OPERATOR, ORGANIZATIONAL DIRECT
LIST FOR LATHE, ENGINE, MOUNTED ON METAL CABINET BASE MODEL 25-451-W/25-651
11. TECHNICAL MANUAL - OPERATOR, ORGANIZATIONAL,
PARTS LIST FOR ENGINE LATHE MODEL NUMBER 2516-20 (3416-00-242-8824) (65 pages)
12. TECHNICAL MANUAL - OPERATOR S MANUAL - FIXTURE, LATHE,
METAL CUTTING FOR DIAMETER ROUND OR 2 INCH SQUARE 360 DEGREE INDEX RING, 2
INCH STOCK, 12-1/2 HIGH, 5 WIDE, 3-7/8 VERTICAL TRAVEL (NUMERIC PRODUCTS
COMPANY MODEL 312) (3(***)-022-8817) (28 pages)
13. TECHNICAL MANUAL - OPERATOR S MANUAL - FIXTURE, LATHE,
METAL CUTTlNG FOR 2 INCH DIAMETER ROUND OR 2 INCH SQUARE STOCK, 360 DEGREE
INDEX RING, 12 HIGH, 5 WIDE, 3 7/8 VERTICAL TRAVEL (DUMORE COMPANY MODEL 8349)
14. TECHNICAL MANUAL - OPERATOR S MANUAL - LATHE BRAKE
DRUM, FLOOR MOUNTED, 60-INCH RATED SWING, 9-TO-25-INCH DRUM DIAMETER,
10-INCH MAXIMUM CUTTING DEPTH, STATIONARY CUTTING TOOL TYPE, WITH GRINDING,
PROVISIONS, 1-HORSEPOWER DRIVE MOTOR, AC, 115-VOLT, 60-CYCLE, SINGLE PHASE,
1/2-HORSEPOWER GRINDING MOTOR, AC, 115-VOLT, 60-CYCLE, SINGLE PHASE (AMMCO
TOOLS, INC MODEL 7700-7) (4(***)-516-6192) (49 pages)
15. TECHNICAL MANUAL - OPERATOR S MANUAL - LATHE, BRAKE
DRUM, FLOOR MOUNTED, 60 INCH RATED SWING, 25 INCH MAXIMUM DRUM DIAMETER,
W/GRINDING PROVISIONS, 1 HORSEPOWER DRIVE MOTOR, 1/2 HORSEPOWER GRINDING
MOTOR, 115-VOLT, 60-CYCLE, SINGLE-PHASE (STAR MACHINE AND TOOL COMPANY
MODEL 1960) (4(***)-516-6192) (26 pages)
16. TECHNICAL MANUAL - OPERATOR S MANUAL - LATHE, BRAKE
DRUM, FLOOR MOUNTED, 60-INCH RATED SWING, 9-TO 25-INCH DRUM DIAMETER, 10-INCH
MAXIMUM CUTTING DEPTH, STATIONARY CUTTING TOOL TYPE, 1/2-HP, AC, 10/220-VOLT,
60-CYCLE, SINGLE PHASE (LEMPCO PRODUCTS, INC. MODEL 802) (4(***)-516-6192) (28 pages)
17. TECHNICAL MANUAL - OPERATOR S MANUAL - LATHE, BRAKE
DRUM, FLOOR MOUNTED 60 INCH RATED SWING, 25 INCH MAXIMUM DRUM DIAMETER,
115-VOLT, 60-CYCLE, SINGLE PHASE (STAR MACHINE AND TOOL COMPANY MODEL 1400)
18. TECHNICAL MANUAL - OPERATOR, ORGANIZATIONAL,
PARTS LIST FOR LATHE, BRAKE DRUM, MODEL 1400 (STAR MACHINE AND TOOL CO)
(4910-00-51 6-6192) (20 pages)
19. TECHNICAL MANUAL - OPERATOR S, ORGANIZATIONAL,
PARTS LIST) FOR LATHE, BRAKE MODEL 1476 (STAR MACHINE & TOOL COMPANY) (NSN
20. TECHNICAL MANUAL - OPERATOR S, ORGANIZATIONAL,
PARTS LIST FOR LATHE, ARMATURE AND UNDERCUTTER MODEL B-10 (FRANK N. WOOD
CORPORATION) (NSN 4940-00-263-3077) (26 pages)
