Fluke 92B scopemeter series ii ocilscpe scope meter 92
* Fluke 92B ScopeMeter Series II
* Fluke PM8918 10:1 Probe (1 Red - 1 Grey)
* Fluke High Voltage Test Pins (1 Red - 1 Grey)
* Fluke Mini Test Hook (1 Red - 1 Grey)
* Phillips Extended Probe Tips (1 Red - 1 Black)
* Fluke Flexible Test Leads (1 Red - 1 Black)
* Fluke PM9081 BNC - Banana Dual
Fluke 92B/003 ScopeMeter Series II, 25 MS/s Dual-Input 60 MHz Oscilloscope
ScopeMeter Series II is a battery powered combonation scope and meter designed for measurments on-the-go. Just push the MEASURE MENU button, select one of 30 measurments, and ScopeMeter Series II Automaticly configures itself to take the desired reading.
With ScopeMeter Series II, good waveforms are automatic. While probing from test point to test point, the CONTINUOUS AUTOSET feature instantly adjusts the timebase and amplitude. Manual controls are still there, but Series II is so fast and easy, why use anything else!
Designed with a sealed, ruggedized case, the ScopeMeter Series II performs reliably, even in wet, dusty, or dirty enviroments. And the backlit screen makes for easy readings in brights light and no light situations.
Whether it's an overheating motor, spikeson a circuit, or dimming, flickering lights, the ScopeMeter Series II is ideal for uncovering the source of power quality problems in complex electrical circuits. Series II gives the best accuracy and versatility available in "on-the-go," battery, powered instruments, and measures automatically.
* Analog-like backlit display
* Full featured true rms multimeter with special modes
* Direct access measurment menu
* TrendPlot current clamp scaling
* Screen transfers can be made to a PC
* Sealed against the elements and protected by a shock resistant holster
* Simultaneously graph and display Min/Max/Average measurments over time for monitoring trends & intermittents
* Print Directly from ScopeMeter Series II, or download to a PC for further analysis.
Min Max TrendPlot - Long Term Recording
Multimeter Display with Full Width Waveform
Time/Division (10 ns/div to 60 sec/div)
Volts/Division (1mV/div to 100V/div
Digital Trigger Delay (Cycles, Events, Time & Zoom
Special Multimode Modes (RPM, Temp & More)
Scope Input Current Clamp Scaling - Read Amps
Continuous Autoset Hands-free signal probing. Continuously follows input sig-nals from 15 Hz-50 MHz and automatically selects theproper time base, input range and trigger level.
MIN MAX Envelope Mode Record the waveform excursions with a gray scale envelope on both inputs.
40 ns Glitch Detect Sweep speeds 1 ps/div or slower on Input A
Analog-Like Grey-Scale Display
Waveform Average Smoothing up to 256 waveforms, 10 samples in Roll Mode
<10 Hz direct, <1 Hz with 10:1 probe
1 mV to 100V/ div to 1 kV/ dlv with 10:1 probe
A,-A, B, -B, A+B, A-B, A=x B=y
1M , 25 pF direct,10 M , 13 pF with 10:1 probe
256 or 512 samples (10 or 20 divisions)
+0.2V or 2.0V (TTL level compatible)
1 M , 25 pF direct, 10 M , 13 pF with 10:1 probe
Re-triggers after 2 to 255 trigger cycles
1 to 1023 events after External trigger
Zoom Magnifies waveform around the 4th division at the next acquisition (sweep)
