Seal image 410 roll lamination 43" wide laminator
* Manufacturer: Seal / Neschen Americas
* Model: Image 410 - 43 Inch Roll Laminator
* Condition: This laminator is in excellent condition. We just installed BRAND NEW ROLLERS! Both rollers heat up fully and it makes a nice finished product with no wrinkles. Laminates documents up to 43 inches wide and includes a very nice rolling stand.
* (From Manufacturer's Brochure) The SEAL Image 410 is the ideal, simple to use laminator for mounting, laminating and encapsulating wide format prints up to 43". Offering programmable control settings, easy material loading and other user-friendly features, the Image 410 is an ideal partner for both new and experienced finishers. Capable of hot or cold operation, the 410 can be used to make flexible and rigid display graphics, backlits, window graphics, floor graphics and more. Ideal for low to medium volume production. Its sleek new design retains a small footprint for shops where space is limited. Features such as digital touch-pad controls with factory presets or user overrides make operation easy without sacrificing performance. The Image 410 allows you to transform printed output into effective and profitable display applications.
* Controls are user-programmable to meet specific applications or to fine tune the finishing process. High-release silicone rollers to minimize adhesive build-up and afford easy cleaning. Digitally-controlled electric heat for accurate, even heating across the rollers. Pull-rollers for smooth performance during encapsulating.
* Specially designed front table with in-feed guides for smooth, wrinkle-free feeds.
* Heat-activated mounting and laminating. Pressure-sensitive mounting and laminating.
* Handles ink jet, photographic, electrostatic and lithographic media.
* Foot controls for hands-free operation. Comprehensive safety systems with emergency stops and electric eyes, plus auditory and visual proximity alarms.
* Digital touch-pad controls with factory and programmable presets for fast, accurate set-up and operation. Motor driven roller adjustment with push-button control of nip and roller pressure. Swing-out supply shafts with Auto-Grip and internal brakes for easy loading and precise film tension adjustment.
* Automatic take-up shaft for removing release liners.
* Maximum working width: 43 in. (109.2 cm)
* Maximum roller speed: 10 fpm (304.8 cm/min)
* Maximum roller temperature: 250 F (121 C)
* Maximum roller opening: 1.125 in. (2.86 cm)
* Roller surface construction: High release silicone coated
* Supply shaft capacities: 3 in. (7.6 cm) I.D. cores
* Maximum substrate thickness: 1 in. (2.54 cm)
