Stero sct-44-csa chemical sanitizing conveyor machine
STERO SCT-44-CSA CHEMICAL SANITIZING CONVEYOR MACHINE
* Design: Single tank 20" rack conveyor warewasher has a power wash and a final sanitizing rinse with flexible strip curtains at each end. A large inspection door allows easy access to the interior of machine. All components are easily accessible for cleaning and maintenance.
* Construction: Tank and hood are formed from 304/18 8 No. 4 mill finish stainless steel, fully welded with a minimum of bolt together construction. Frame is heavy-duty stainless steel flat stock construction conforming to NSF Standard No. 3. Machine is supported by enclosed stainless steel feet. All internal piping, fittings, risers and manifolds are stainless steel.
* Power Wash: STEROs unique stainless steel manifolds are center-fed, fitted with stricture free jets with directional vanes and can be easily removed without tools. Center-fed manifolds distribute an even flow of wash water over the entire perimeter of the rack, ensuring consistent results. The SCT-44 distributes 300 GPM of detergent water over the ware with a 2 HP motor and pump assembly. The SCT-44-10 also has 300 GPM of detergent water pumped by a 2 HP motor. Motor has extended stainless steel shaft with packless ceramic seal and stainless steel impeller that aligns perfectly with the pump housing. The pump has easily removable front and end inspection plates and is self-draining. Stainless steel perforated strainer pans cover the tank of each model.
* Automatic Fill: Fills the machine at the push of a button and keeps it full during operation. In the event of low water in the tank, the system will automatically re-fill to the proper level.
* Automatic Start: Rack activated switch starts conveyor and pumps eliminating the need for a manual start.
* Automatic Shut Down: Shuts down machine operation during idle periods.
* Stainless Steel Front Enclosure Panel: Protects motors and controls from moisture.
* Kit 55: STERO mounts a 3/4" pressure reducing valve, shock-arrestor and flow pressure gauge in the final rinse line prior to the rinse solenoid valve. The shock-arrestor prevents line hammer and will double the life of the valve. The PRV will allow adjustment of the final rinse pressure and the gauge will give visual proof when it is correct.
* Common Drain: STERO connects overflow and drain valves so that one drain rough-in will service the entire machine.
* Motors: 2 HP, 1750 rpm, 300 GPM, heavy duty with sealed bearings and overload protection.
* Final Rinse: Stainless rinse arms mounted above and below are fitted with directional fanjets that create a full coverage spray pattern for maximum rinsing and sanitation. The rack activates STEROs final rinse switch and hot water solenoid valve with stainless steel seat. A vacuum breaker mounted downstream from the solenoid and 6" above the upper rinse completes STEROs rinse system. The SCT-44-CSA sanitizes with chlorine which is dispensed by STEROs peristaltic pump. The CSA eliminates the need for a 180 final rinse booster.
* Thermometers: One each for wash and final rinse.
* Standard Electrical Features: All motors on STERO conveyor machines are factory wired in waterproof conduit and fittings to a common connection point. The motors are protected by thermal-overloads with manual reset buttons. The magnetic motor starters, start-stop switches, and electric tank heating element contactors (when specified) are mounted in a stainless steel control box.
* Standard Electrical Specifications: 208/240-60-1, 208/240-60-3, 460/480-60-3.
* Door Safety Switch: Prevents the machine from operating if the door is open. The machine will automatically shut-off if the door is opened while the warewasher is running.
* Bell-Type Stainless Steel Skimmer: With hinged cover. Acts as overflow and facilitates removal of fats and oils from the wash tank.
* Drain Valves: STERO designed poppet-type drain valve, stainless steel seats and casting assures leak proof and trouble free life. Externally controlled with spring-loaded shafts to prevent damage. The finest in the industry.
NSF requires that water in all power wash tanks be maintained at specific temperatures.
* Please see manufactures website for further information.
