14" swg 40" cc jones & shipman 1079-eiu od grinder, swg
MODEL: 1079 S/N: BO-16402 NEW: 1989
MAXIMUM SWING .................................. 14"
DISTANCE BETWEEN CENTERS ........................ 40"
TABLE SWIVEL INCLUDED ANGLE ..................... 16 DEG.
LONGITUDINAL TABLE SPEED (HYDRAULIC) ...... 3" TO 180" IPM
FINE HAND TRAVERSE KNOB GRAD. ................... 0.0005"
FINE HAND TRAVERSE KNOB PER REV. ................ 0.01"
TABLE SWIVELS, CLOCKWISE ........................ 15 DEG.
TABLE SWIVELS, COUNTER-CLOCKWISE ................ 16 DEG.
TRAVERSE AMOUNT ON SCREW ........................ 7"
POWER WHEELHEAD RAPID STROKE .................... 1- 1/4"
CROSS FEED HANDWHEEL GRAD. ...................... 0.0002"
FINE FEED LEVER GRAD. ........................... 0.00005"
AUTO INFEED INCREMENT ..................0.00002" TO 0.0020"
PLUNGE INFEED RATE ........................ 0.00005" TO 1"
WHEELHEAD SWIVELS .............................. 360 DEG.
WHEEL SIZE ............................. 12" x 1- 1/2" x 5"
WHEEL SPEEDS (2) ........................ 1,550 & 1,990 RPM
WHEELHEAD MOTOR ................................. 5.5 HP
WORKHEAD SPINDLE SPEEDS (6) ................. 40 TO 320 RPM
APPROX. FLOOR SPACE REQUIRED ................. 120" X 68"
APPROX. MACHINE WEIGHT ........................ 8,500 LBS
- AUTO INFEED OF WHEELHEAD @ TABLE REVERSAL
- PLUNGE INFEED (CONINUOUS FEED) W/DUAL COARSE & FINE INFEED
- POWER RAPID WHEELHEAD ADVANCE & RETRACTION
SPARKOUT TIMER (0 TO 30 SECONDS)
WHEELHEAD MOVES ON ROLLER BEARINGS
WHEEL CAN BE MOUNTED ON LEFT OR RIGHT SIDE OF WHEELHEAD
FINE FEED MECHANISM FOR INFEED OF WHEELHEAD (.00005")
SWING AROUND INTERNAL GRINDING ATTACHMENT W/SPINDLE
"HEIDENHAIN" SINGLE AXIS DIGITAL READOUT DISPLAY FOR THE
WIRED PRESENTLY FOR 3/60/440 VOLT OPERATION
