Bk precision model 3001 audio generator w/box, manual
BK Precision Model 3001 Audio Generator
This device is in perfect working order and in excellent cosmetic condition. It appears unused, but there are some scratches inside the battery compartment. It runs on a 9V battery (not included).
* 20 Hz to 150 kHz Sine/Square Wave Audio Generator
* Sine and square wave generator
* 20 Hz to 150 kHz in 46 steps
* Low distortion RC oscillator
* Compact, fully portable, light weight
x1 range 20 kHz to 1.5 kHz (23 steps), x100 range 2 kHz to 150 kHz (23 steps)
20 Hz through 100 kHz (+-3% or less), 120 kHz and 150 kHz (+-5% or less)
0 dB/-20 dB attenuator switch and variable amplitude control
> 1.2V rms at max. setting (no load)
(Short term) 20 Hz to 150 kHz +-0.5dB (reference frequency 1 kHz)
200 Hz - 15 kHz 0.5% (THD) or less, 50 Hz-28 kHz 0.1% (THD) or less, 20 Hz-100kHz 0.3% (THD) or less
Less than 5% at 20 Hz (DC coupled)
<2% from maximum output, to 50mV p-p
Other specifications same as sinewave characteristics
0 0 C to +50 0 C; specifications apply from 10 0 C to 30 0 C, <80% R.H.
-20 0 C to +60 0 C, without battery
35 hours typical with Alkaline
7 oz. (200g) including battery
$9.99 to all provinces (delivery in 1-7 business days)
$10.99 by Airmail Small Packet (delivery in 5-10 business days)
$14.99 by Surface Parcel (VERY SLOW DELIVERY in 6-8 weeks MINIMUM)
$18.99 by Airmail Parcel (delivery in 5-10 business days)
