Oriel optical ss honeycomb breadboard isolation table
Oriel Optical SS Honeycomb Breadboard Isolation Table
Came from Reynolds Metals when
& has been lost it in my warehouse
* Measurement - 41-1/2" x 71-7/16" x 4", 35" minimum height
* Magnetic Stainless Steel Top (Not Magnetized)
* Construction - Bonded sandwich structure
* Top Plate - 1/8" (3.2mm) thick ferromagnetic stainless steel
* Core - 5.2 lb/ft3 (83.5 kg/m3) aluminum honeycomb
* Bottom Plate - 1/8" (3.2mm) thick carbon steel
* Finish on Top - Smooth sanded
* Finish on Bottom - Painted
* Flatness (top) - Better than +/- 0.005" (+/-0.127mm) anywhere inside the hole pattern
* Typical static rigidity* - 0.47 m/inch/lb (0.25 m/kg)
* Deflection/unit force at the center when the tabletop is mounted at normal support points
* Economical, compact, suitable for general purpose optical experiments and interferometric work
* Damped honeycomb Tech Base and sturdy frame with vibration isolation supports
* Tech base for Laser and optical light source (Laser & Optical Light Source Not Included)
Descriptions are Intended Only as a Guide
and Their Accuracy Should be Checked with the Manufacturer.
Common Carriers charge extra to unload, move items inside your building, and delivery to all residential addresses.
This means you must have the equipment and ability to unload from the end of the truck and put your purchase where you want it.
Property and Condition is as Described"
