This Awesome Semi -hardcover text
for any Serious Boiler Designer,
Engineer, Boilerman or Restorationist
Boiler Construction Techniques.
" AUDELS ENGINEERS AND MECHANICS GUIDE # 5 "
A Progressive Illustrated Series
With Questions ~ Answers, Calculations,
Especially Prepared for all Engineers all Mechanics and all Electricians.
A Practical Course of Study and Reference for all Students and
Workers in Every Branch of the
AUTHOR ~ Frank D. Graham, B.S.,M.S.,M.E.
AND STEVENS INSTITUTE ~ LICENSED
STATIONARY AND MARINE ENGINEER
Published by THEO. AUDEL & CO., PUBLISHERS
This Beautifully written and illustrated text
is a Killer information source on
Marvelous semi - gloss pages are cream colored,
supple and tightly bound inside.
The Gold Gilt lettering is Excellent!
The Red page edges are Beautiful!
There is a Previous Owners Name
and Address Written on the Inside Front Cover.
Other Than That the interior is Pristine!
This is a Fine, Clean and Tight copy.
For an 69-year-old teaching guide it is in Awesome shape!
The condition is considered " FINE + " by industry standards.
This awesome study book was used to
Assist Professors, Students, Mechanics, Engineers
and Laymen alike in their acquisition of knowledge.
It is filled with exquisite pen and ink line Drawings,
Illustrations, Tables, Graphs and Pictures.
This masterpiece is surrounded by Blind Stamped black covers,
Gold Gilt Lettering on the Spine and Gold Edge pages!
It measures in at 5" by 6 5/8".
This Awesome Nine Chapter text
has 507 pages, plus a 24 page Index
Plus 5 pages of Turn of the Century
Advertisements for a total of 536 pages of
not easily found in modern books!
Learn to Analyze CO2 Readings!
Do you Know what a Homogeneity Test
Do you Know how to make Superheated Steam?
Do you Know what the Allowable Stresses are for Stay Bolts?
You Could be Heating your Pooches Dog House in No Time!
This is Vol. 5 of an Awesome 8 Volume Set!
If you are interested in completing a set you already have or
want to build a set for your library, go to my
Before They Have Learned the Theory,
Resemble Sailors Who Go to Sea
" A Little Knowledge Is A Dangerous Thing!"
Massive amount of information.
Chapters and Subchapters of this text.
Conductivity of Absorption of Heat;
Effect of Pressure on Melting Point;
Contraction and Expansion of the Liquid;
Internal and External Latent Heat;
External Work of Vaporization;
Total Heat of Saturated Steam;
Comparative Evaporation of Coal and Oil;
Determination of Heating Value
Available, High and Low Heating Values;
Heating Values of Gaseous Fuels;
Orsat Three and Four Pipette Apparatus;
Flue Gas Analyzers v.s. CO2 Recorders
VARIOUS HORIZONTAL SHELL BOILERS
Difference Between a Tube and a Flue;
Various Furnace and Combustion Chamber Arrangements;
Difference Between a Boiler and a So - called Generator.
Importance of Rapid Circulation;
WATER TUBE AND SHELL BOILERS COMPARED
Quality of the Steam with Through and Submerged Tubes;
Comparison of External and Internal Furnaces.
Development of the Shell Boiler;
Evolution of the Horizontal Return Tubular Boiler;
Lancashire ~ Galloway Boilers;
Difference Between Clyde and Scotch Types;
Non - sectional and Sectional Boilers;
Author's Home Made Series Pipe Boiler;
Mosher Boiler of Launch Norwood;
Closed Tube or Porcupine Boilers;
Series Parallel Tube Arrangement;
Up Flow and Down Flow Boilers.
Horizontal Boiler Vertically Set;
Vertical Extended Internal Fire Box;
2. COMBINED FLUE AND FIRE TUBE BOILERS
Cornish and Lancashire Boilers with Fire Tubes;
3. WATER TUBE ( OR PIPE ) BOILERS
4. COMBINED FIRE TUBE ( OR FLUE ) AND WATER TUBE BOILERS
Internal Firing with Large Water Capacity;
Single and Double Row of Water Tubes;
5. COMBINED SHELL AND WATER TUBE BOILERS
6. COMBINED SHELL, FIRE AND WATER TUBE BOILERS
Heating Surface ( Usually Ridiculously Small );
Effect of Inadequate Heating Surface;
Efficiency of Heating Surface;
Author's Home Made Pipe Boiler;
DETAILS OF STRENGTH AND CONSTRUCTION
A.S.M.E. STANDARD FOR VARIOUS JOINTS
Riveted Socket and Through Stays or Stay Rods;
Gusset, Palm, Crow Foot, Jaw and Angle Stays;
Allowable Stresses for Stays and Stay Bolts;
WATER TUBE BOILER CONSTRUCTION
For the book collector, the text and pictures are an incredible
blast into the past of a bygone era of nostalgia!
If you're a any Serious Boiler Designer,
