Smt 0603 ceramic capacitor kit #2 (#3560)
SMT 0603 Ceramic Capacitor Kit #2 (#3560)
This 0603 SMT Ceramic Capacitor Kit #2 has 10 pieces each of 33 different common Ceramic Capacitor values in the 0603 SMT package, except for the last two values which get 5 pieces each. Each SMT Capacitor is rated for 50 Volts, 5%, except as noted. There are a total of 340 SMT Ceramic Capacitors in this great kit. It includes values of SMT Ceramic Capacitors in the picofarad range from 100pF to 4.7uF. Since 0603 components are very small, each strip of capacitors is marked with the value. Included in this kit are mini zip-lock bags for easy storage and identification.
NPO capacitors have a linear temperature coefficient over the range of -55 C to +125 C, low loss, and have a negligible change of electrical properties with time, voltage, and frequency. The lower picofarad capacitors are typically NPO (COG) and have a better Tolerance than 5%.
X7R dielectric capacitors have a non-linear temperature coefficient over the range of -55 C to +125 C, low loss, and have a good aging rating. The higher picofarad caps are typically rated as X7R . This kit includes both NPO & X7R dielectric capacitors. You get the following:
100pF, 50v, NPO, 5%, Ceramic, 0603
120pF, 50v, NPO, 5%, Ceramic, 0603
150pF, 50v, NPO, 5%, Ceramic, 0603
180pF, 50v, NPO, 5%, Ceramic, 0603
200pF, 50v, NPO, 5%, Ceramic, 0603
220pF, 50v, NPO, 5%, Ceramic, 0603
270pF, 50v, NPO, 5%, Ceramic, 0603
330pF, 50v, NPO, 5%, Ceramic, 0603
390pF, 50v, NPO, 5%, Ceramic, 0603
470pF, 50v, NPO, 5%, Ceramic, 0603
680pF, 50v, NPO, 5%, Ceramic, 0603
820pF, 50v, X7R, 5%, Ceramic, 0603
1000pF, 50v, X7R, 20%, Ceramic, 0603
1500pF, 50v, X7R, 5%, Ceramic, 0603
1800pF, 50v, X7R, 5%, Ceramic, 0603
2200pF, 50v, X7R, 5%, Ceramic, 0603
3300pF, 50v, X7R, 5%, Ceramic, 0603
3900pF, 50v, X7R, 5%, Ceramic, 0603
4700pF, 25v, X7R, 10%, Ceramic, 0603
5600pF, 50v, X7R, 5%, Ceramic, 0603
6800pF, 50v, X7R, 5%, Ceramic, 0603
8200pF, 50v, X7R, 5%, Ceramic, 0603
.01uF, 50v, X7R, 5%, Ceramic, 0603
.015uF, 50v, X7R, 5%, Ceramic, 0603
.022uF, 50v, X7R, 5%, Ceramic, 0603
.027uF, 16v, X7R, 10%, Ceramic, 0603
.033uF, 16v, X7R, 10%, Ceramic, 0603
.047uF, 25v, X7R, 10%, Ceramic, 0603
.10uF, 25v, X7R, 10%, Ceramic, 0603
.12uF, 25v, X7R, 10%, Ceramic, 0603
.18uF, 25v, X7R, 10%, Ceramic, 0603
.22uF, 10v, X7R, 10%, Ceramic, 0603
.47uF, 10v, X7R, 10%, Ceramic, 0603
1.0uF, 16v, X7R, 10%, Ceramic, 0603
4.7uF, 6.3v, X7R, 20%, Ceramic, 0603
