14" swg 40" cc sharp 1440F engine lathe, 16 speed heads
14" Swg 40" cc Sharp 1440F ENGINE LATHE, 16 Speed Heads
14" Swing 40" Centers Sharp 1440F ENGINE LATHE, 16 Speed Headstock
- jog button for easy engagement of gears & inching spindle
- larger compound, tailstock & apron than competitive models
allows heavier cutting with less vibration
- 16 speed ("F" models), all geared headstock housed inside a
- quick-change gearbox offers wide range of threads
Spindle nose type: D1-4 Camlock
Spindle Speeds: 45 - 1,800 RPM (16 speeds)
Longitudinal feeds - inch per rev (40): 0.0012 - .0294"
Cross feeds - in/rev (40): 0.0003 - 0.01"
Inch threads (40): 4 - 112 TPI
Metric threads (22): 0.45 - 7.5mm
Leadscrew pitch, diameter: 8 TPI, 7/8"
Compound width x length: 3-1/2 x 8-1/2
Quill travel (graduated): 4-1/2"
SPECIFY: 220V or 440V, 3 Ph, 60 Hz
Net weight (approximately): 1,650 lbs
coolant system, 4-way toolpost, steady rest, thread dial, foot
brake, center sleeve (MT #5 x #3), dead centers (MT #3) tool kit,
removable gap block & splash guard.
Follow rest, digital readout system, taper attachment, micrometer
carriage stop, 3-jaw scroll chuck (8"), 4-jaw chuck (8"), face plate
(12"), single toolpost, live center (MT #3), & drill chuck.
