5310ZZ nachi double row angular contact bearing japan
Nachi Double Row Angular Ball Bearings
5310 Nachi Double Row Angular Ball Bearings, Double Shielded, Made in Japan, here are the dimensions of the 5310, the 5310 inner diameter is 50mm, the 5310 outer diameter is 110mm, 5310 width is 44.4mm.
* Item: 5310 Double Row Angular Ball Bearings
* Dimensions: 50*110*44.4 mm/Metric
* ID (inner diameter)/Bore=50mm
* OD (outer diameter D1)=110mm
* Width/Height/thickness=44.4mm
* 5310 Type: Nachi Double Row Angular Ball Bearings
* 5310 Closures: Double Shielded
* Size: 50mm x 110mm x 44.4mm
* Quantity: One Bearing 5310
Nachi Double Row Angular Contact Bearing
The construction of this type ball bearing is similar to the adjacent, BACK-TO-BACK mounting of two Single-row Angular Contact ball bearings. Because fewer balls can be inserted per row compared to Single-row Angular Contact ball bearings, a Double-row Angular Contact ball bearing will have less load capacity than an equivalent size/series BACK-TO-BACK set of two Single-row Angular Contact ball bearings. This bearing type can sustain radial, moment and bi-directional axial loads.
