Hydrualic technology filler/bleeder unit test 9701
Our Asset #:DRW23 - 23 Qty available:1
Hydrualic Technology Filler/Bleeder Unit test 9701
Condition: 4. USED: Tested in our shop Guaranty: See our 7 day DOA Guaranty!
Manufacturer: Hydrualic Technology
HP/Amp/KW/KVA:1 MP (1 man power) Voltage: Phase: 1 Other Info:
Picture 265.jpgPicture 268.jpgPicture 267.jpgPicture 266.jpgPicture 269.jpgPicture 264.jpgdrw23 090.jpgdrw23 089.jpg
9701 Filler-Bleeder.bmp (316034 bytes)
Filler and Bleeder, Hydraulic, Aircraft
P/N 9701, 9701A, NSN 4910-01-437-0442, MIL-F-83766A
The Hydraulic Filler and Pressurization Unit, commonly known as a Filler/Bleeder Unit, serves as a mobile maintenance unit for use in hangars and on flight lines for servicing the hydraulic systems of aircraft having a system pressure from 0-3000 psi. The Filler/Bleeder is manufactured in accordance with MIL-F-83766A. The unit is essentially composed of a 19 gallon capacity hydraulic reservoir with inlet and outlet strainers, low pressure transfer pump, high pressure pump, low and high pressure relief valves, and a 3 micron absolute filter assembly conveniently located on a three wheeled trailer . A " ID x 25ft. long MS28759-8 service hose with end fittings conforming to MS28760-8 is used to connect the unit to the item being serviced and is stored in an integral storage cabinet.
Fluid Type - MIL-H-5606 or equiv.
Asset Location: TX Del Rio 78840 Area: yard
Length: 48 Width: 26 Height: 32
a. Est. Wt. each: 238LBS b. Est. pkging wt: 30 c. Est. total wt: 268
