Lubrication service unit, trailer mounted, lube
Lubrication Service Unit, trailer mounted, Lube
This is a self-contained grease, lube oil, motor oil and air supply servicing unit. The package consists of a gas powered air compressor, one engine oil pump and tank, a gear oil pump and tank, a grease pump and tank, and five retractable hose reels and nozzles. All of this is mounted on a skid that is mounted on a trailer (call us if you do not want the trailer).
This unit was reconditioned in 1991, and then reconditioned again more recently and was not fully assembled. The pumps, tank, and overhead frame need to be mounted. The air supply lines need to be run to the three pumps. The grease and oil delivery lines also need to be run from the pumps to the hose reels. The tank needs to be painted as well. We have a unit that is complete and using it as an example everything looks very straight forward.
The package can be removed from the trailer and installed in the back of a pickup or other vehicle. The trailer brake lines and components need to be installed. Unit seems complete otherwise. This unit would be perfect to maintain fleet vehicles or equipment out in the field. We are also offering a unit that is fully assembled, and also parting one unit out. Please call (***)-286-1655 with any question.
* Missing some brake air components
* Tank and diagram/master cylinder assembly included
* Gladhand airlines missing
* Air over hydraulic brakes
* retractable landing gear
* Lube skid - easily removed from trailer
* Frame not attached to skid, tanks unbolted from frame
* skid and trailer weight: 5150 lbs
* Engine oil nozzle Alemite meter - Model: 3685-1 (appears unused)
* Gear lube nozzle Alemite meter - Model: 3683-A (appears unused)
* Gun for grease GAA reel.
* Air reel is terminated with a quick disconnect.
* Each reel has 50 feet of hose
* size: 4 3/8 x 2.5 x 1 5/8
* Engine and compressor mounted on air tank
* engine and compressor are complete
* Ignition toggle and push start button
* Throttle and choke adjustments
* Two Alemite pumps and one Graco pump sitting unbolted on 3 compartment tanks.
* Pumps freshly painted and appear rebuilt. Tank requires painting
* Pump Model: president , 205-629
* Air motor: model: 205-647 , series C87K
* Appears unused or rebuilt
