Epson tm-T88IIS model M129B thermal receipt printer
Epson TM-T88IIS Model M129B Thermal Receipt Printer
General Print method : Thermal line printing
Print font : Font 9 x 17/12 x 24
Column capacity : 56/42 columns
Character size : 0.99(W) x 2.4(H)/1.41(W) x 3.39(H)mm 0.039 x 0.095 /0.056 x 0.133
Character set : 95 Alphanumeric, 37 International, 128 x 8 Graphic Traditional/Simple Chinese, Thai, Japanese, Korean
Bar code : UPC-A, UPC-E, JAN8 (EAN), JAN13 (EAN), CODE 39, CODE 93, CODE 128, ITF, CODABAR
Characters per inch : 20 cpi/15 cpi
Printer Interface : Serial RS-232C
Print speed : (max.) 150mm 5.9 /sec. (47 lps, 1/8 conversion)
Paper dimensions Roll paper : 79.5 0.5(W) x diameter 83.0mm 3.13 0.02 x diameter 3.27
Paper thickness : 0.06 to 0.07mm {0.0024 to 0.0028 }
Power consumption : Approx. 1.8A (mean)
Reliability : MTBF 360,000 hours, MCBF 52,000,000 lines
Overall dimensions : 145 x 195 x 148mm (W x D x H) {5.71 x 7.68 x 5.83 }
Power supply : PS-180(not included)
See below for complete warranty information
* 1 Epson TM-T88IIS Printer M129B Black version
* Interface is Serial Version
* Power cord or Power Supply
Manuals & drivers available online, see below for details
* By purchasing an item from us, you automatically agree to any and all store policies.
* 8.25% sales tax applicable to Texas residents.
* No charge for local pickup.
* Pictures are representative of the product you will recieve, but may not be the actual item you will receive.
* We will do everything possible to resolve the situation.
* 20% Restocking fee on all returned items for refund.
* All warranty inquiries should be sent to: ****@str-s.com
* All return/warranty items must be packed securely, we are not responsible for damage caused by poor packing.
* We reserve the right to charge fees for items broken in transit due to poor packing.
* There is no warranty on used toner cartridges.
* All items are securely and safely boxed with bubble wrap and foam.
When you contact STRS, be assured you will be communicating with an industry expert with many years of hands on experience. We have been refurbishing and recycling terminals, printers and electronic equipment for over 18 years with an excellent reputation!
Contact us today to see how we can cut your expenses and increase your productivity in this time where every penny counts!
Superior Terminal Repair & Sales
E-mails not answered on the weekend.
My printer didn't come with a users manual or driver disc, how can I get a copy?
We do not include hard copies of users manuals, or drivers because of the amount of different equipment we service and they are readily available for download online. Visit our about us page for links to these downloads.
What kind of port do I have or need for my printer?
There are several different types of ports that a printer can use including Serial, Parallel, USB, Ethernet, IDN, etc.. Here are diagrams to help you identify the ports on your PC and printer:
What does ei and oki emulation mean?
Some Okidata printers have different emulations or firmware not able to be changed in the menu. Software systems require certain versions of these printers and we can do this by replacing the firmware chip on the logic board when we are refurbishing the printer. If you have a printer and you want to know what emulation you have, load the printer with paper, turn off the printer and then turn the printer on while holding the line feed button. The emulation will be one of the first things printed in the top left corner of this self test page.
What is the page count on this printer?
Due to the volume of printers we refurbish, we do not guarantee page counts. All of our printers are completely disassembled, repaired and refurbished using a combination of new and used parts. The print engine is a hybrid of different printers and we guarantee that it will perform like new or better.
What type of keyboard do I need for my Wyse terminal?
You can tell what type of keyboard you have by counting the amount of function keys. Ascii keyboards have 16 function keys, PCE keyboards have 12 function keys, Ansi keyboards have 20 function keys and a do button.
What is your definition of 'refurbished'?
We refurbish each type of product we sell differently. Visit our about us page for an explanation of our refurbishing process.
How can you offer such a long warranty on refurbished items?
As explained in our refubishing process, we are very thorough and have been repairing and renewing equipment for years. Our attention to detail, thorough testing and impeccable packing all contribute to a very low failure rate and allow us to offer long warranties on all our items.
I do not know how to setup the network card in my printer, can you help?
We are here to help, but before contacting us, please read the users manual for setup information. Helpful links to users manuals online and setup guides for all our products are available via our about us page.
There was damage to the package when it was received, what do I do?
Please make note of the damage, take pictures when possible and immediately unbox the item. Test the equipment and look for damage to the exterior of the item. Contact us if there is any problem and we will resolve the situation.
Do I need an RMA to send a product in for a return or repair?
You do not need an RMA, but you will need to contact us before sending in your item. After you speak with one of our salespeople, mark on the outside of the box 'return deptartment' or 'repair department.' Also, please include a copy of your invoice or a sheet of paper with all of your contact information, as well as a detailed description of the problem you are having with the equipment.
