75 pcs. coilcraft# DO3316P-683, surface mount power ind
The following item has just been added to our store in a larger qty. This item is for 75 pcs. only!
= 20%, K = 10% (Table shows stock tolerances in bold.)
= RoHS compliant gold over nickel over phos bronze.
T = RoHS tin-silver-copper (95.5/4/0.5) or
= 13 machine-ready reel. EIA-481 embossed plastic
tape (1000 parts per full reel).
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
2. Tested at 100 kHz, 0.1 Vrms, 0 Adc using an Agilent/HP 4263B LCR
4. SRF >13 MHz measured using Agilent/HP 8753D network analyzer;
<13 MHz using Agilent/HP 4192A.
5. DC current at which inductance drops 10% (typ) from its value without
6. Current that causes a 40 C temperature rise from 25 C ambient.
7. Electrical specifications at 25 C.
Refer to Doc 362 Soldering Surface Mount Components before soldering.
