Yfe high stability insulation tester tf-504 free ship
YFE High Stability Insulation Tester TF-504
This is a compact easy-to-use insulation tester to be used at teh work site. The high stability insulation tester uses an electronic DC to DC Converter operated with the dry batteries (UM-3x6pcs) for power supply. Also, this tester employs a taut band meter movement as the indicator and its outer case is made of high impact plastic, which is strong and light weight. The insulation resistance and AC voltage are capable of measurement. Superior reliability and precision are suit for electric and electronic engineer applications.
* Rated Voltage: DC 1000V +/- 10%
* Measuring Range: 0-1Mohm - 2000Mohm
* Insulation Measurement: 1Mohm - 2000Mohm
* Within +/- 5% reading value
* Center scale: over 90% of rated voltage
* Infinity scale: +/- 10% of rated voltage
* Zero and infinity within +/- 0.9% of teh scale length
* AC Voltage: Within +/- 4% of the full scale vaue
Dimension 169 (L) x 106 (W) x 36 (H) mm.
Weight: About 430g (with 6 Batteries).
