10' x 1/4" cincinnati 2CC10 power squaring shear, 1985
10' x 1/4" CINCINNATI 2CC10 POWER SQUARING SHEAR, 1985
10' X 1/4" CINCINNATI MECH. POWER SQ. SHEAR
MODEL 2CC10 S/N 44326 NEW 1985
CAPACITY .......................................................................... 1/4"
DISTANCE BETWEEN HOUSING ...................................... 10'3"
BACK GAUGE RANGE ........................................................ 0 - 36"
RAKE TAPER PER FOOT .................................................... 1/4" P/FT
STROKES PER MINUTE ...................................................... 60
HOLDDOWNS ...................................................................... 11
GAP (BETWEEN HOUSING & TABLE) .............................. 4"
MAIN DRIVE MOTOR ......................................................... 7.5 HP
AUTOMATIC PRESSURE LUBRICATION
INTERLOCKED STEEL CONSTRUCTION FRAME
MAIN MOTOR: 230/460/360 / 7.5 HP / 3PH
