25"/52" x 48"/84" stanley sliding bed gap lathe w/taper
25"/52" x 48"/84" STANLEY SLIDING BED GAP LATHE w/TAPER
25"/52" x 48"/84" STANLEY SLIDING BED GAP LATHE
NEW: 1956 & FULLY RECONDITIONED IN 1976
SWING OVER BED ............................ 26"
SWING OVER COMPOUND REST .................. 18"
SWING IN GAP .............................. 52"
MAXIMUM SIZE OF GAP ....................... 36"
BASE LENGTH, BED CLOSED ............. 48"
BASE LENGTH, BED EXTENDED ........... 84"
SPINDLE SPEEDS (18) ....................... 7 - 330 RPM
HOLE THRU SPINDLE ......................... 3-5/8"
THREAD RANGE ENGLISH ...................... 2 - 28 TPI
THREAD RANGE METRIC ....................... 1 -20 MM
SPINDLE CENTER ............................ #5 MT
SPINDLE TRAVEL & SET OVER, RIGHT OF LEFT .. 12"
APPROX WEIGHT ............................. 10,500 LBS
FLOOR SPACE, BASE LENGTH CLOSED ........... 144"L x 72"W
FLOOR SPACE, BASE LENGTH EXTENDED ......... 180"L x 72"W
MANUAL OPERATED SLIDING BED FOR INCREASED
SPECIAL BACKREST FOR TURNING FULL DIAMETER IN GAP
INCH / METRIC THREADING CAPABLITY THRU CHANGE GEARS
CONDITION: ***** EXCELLENT *****
