Hitek dual hv dc power supply -1KV 10MA/ -2KV 5MA PSM10
Hitek DUAL HV DC Power Supply -1kV 10mA/ -2kV 5mA PSM10
PSM10 Precision Scientific Power Supply Module Common Specifications:
* Voltage and Current control capability
* Voltage and Current monitor
* Short circuit & flashover protected
* Regulation (line & load): <0.005%
* Voltage or Current control: 0-10V = 0-full voltage
* Voltage setting: 10-turn, locking, vernier potentiometers
* Voltage & Current monitors: 0-10V = 0-full voltage/current
* Reliability: MTBF >100,000hrs (in accordance with military specification MIL-HDBK-217F)
* Output Voltage: 10V to 1,000V
* Output Current: 10mA (max)
* Output Stored Charge Energy: <45 C
* Output Voltage: 10V to 2,000V
* Output Stored Charge: <35 C
The Series PSM10 is a range of versatile high voltage component power supply modules equally suited to both laboratory and development work and for specification in OEM equipment. Powered from 24V DC, these units allow full range control and monitoring of voltage and current via 0-10V analogue signals and inhibit signal input. As well as photomultipliers, the PSM10 is suitable for gamma cameras, image scanners, spectroscopy, scintillation counters, microchannel plates, piezo crystal devices, ultrasonic transducers, electron beam deflection, electrorheological fluids, and electrostatic lenses (SEMs and STMs).
