Yaesu vx-6R dualband two way dual-band radio VX6R
YAESU VX-6R Amateur Handheld Transceivers
The Yaesu VX-6R is a triple band (2M, 220 & 440 MHz) HT with extensive receive coverage, and leading-edge features. It is an easy-to-use "little brother" to the VX-7R, and is both submersible (JIS7: 30 minutes of submersion at depth of 3 feet) and extremely rugged. The VX-6R provides wide receiver coverage at 504 kHz ~ 998.99 MHz (cellular blocked), and puts out 5 Watts of power on the 144 and 430 MHz bands (1.5 W on 222 MHz). The standard memory has 900 channels with 6-digit alpha numeric tag, and 24 memory banks for channel allocation.
222 - 420 MHz (ACT1: Action Band 1)
803 - 998.99 MHz (ACT2: Action Band 2 Cellular Blocked)
11-16 VDC Negative Ground EXT DC Jack
1.6 Amps (5 Watts TX, 144 MHz)
Case Size: 2.3x3.5x1.1 inches (58x90x29 mm) (without knob and antenna) 9.5 oz (270g)
1.5 V for 10dB S/N (0.5-30MHz, AM)
1.0 V for 12dB SINAD (59-108 MHz/470-540MHz, W-FM)
0.5 V for 12dB SINAD (54-59MHz/300-420MHz, N-FM)
0.18 V for 12dB SINAD (420-470 MHz N-FM)
144/430 MHz 5.0/2.5/1.0/0.3 watts
* - 1x FNB-80Li 7.2v 1400Mah Battery
* - 1x NC-72C or NC-72U Charger .
