> Drake tr-3 manual w/foldout schematic »r²
Drake tr-3 manual w/foldout schematic »r²
This is a digitally copied and enhanced manual for the Drake TR-3 transceiver. It is clear, clean, and easy to read. It is printed on premium 24# paper with heavy covers and bound with a plastic comb. No more struggling with unreadable photocopies!
The TR-3 manual is about 8 1/2" X 11" and consists of about 40 pages plus a large one piece 11" X 17" fold out schematic. Topics include general description, installation instructions, control functions, operation, theory of operation, service data, alignment instructions, resistance chart, voltage chart, AC-3 power supply instructions, DC-3 power supply instructions, remote VFO instructions, and parts layout.
Please note that most manufacturers produced many variations within each model. Know your radio and firearms and use care when using the information found in the manuals. Use care - these radio and firearmss contain lethal voltages.
