Tektronix P6046 differential oscilloscope probe and amp
Tektronix P6046 Differential Oscilloscope Probe and Amp
The P6046 is a self-contained active differential system consisting of a differential probe, amplifier and power supply. Active FET amplifiers at the dual-inputs reduce circuit loading. Combined with the differential processing occuring in the probe head, the P6046 provides superior common mode rejection ratios (CMRR) at high frequencies typically 10,000:1 out to 50 kHz, derating to 5,000:1 at 1 MHz. Since the P6046 is self-contained, it provides a differential output into a single oscilloscope channel. System controls enable you to select AC or DC coupling, and adjust the DC balance and select mV/div from 1 to 200mV in standard 1,2,5 steps.
