Aerotech AVS105 motorized lift vertical linear stage
AEROTECH 100-50-U-20P LINEAR STAGE MOTION CONTROL
* Configuration: Single Axis
* Total Travel, XYZ: X: 1.97 in (50 mm)
* Mechanical Drive System: Precision Ball screw
* Stage Bearing Type: Ball Bearing
* Screw Pitch: 12 turns per inch
* Linear Accuracy: 0.00004 in/in
* Stage Length: 8.60 in (218 mm)
* Stage Width: 4.00 in (102 mm)
* Table Length: 4.00 in (101.60 mm)
* Table Width: 4.00 in (101.60 mm)
* Tabletop Height: 1.45 in (36.83 mm)
* Maximum Payload: 50.00 lb (22.68 kg)
* Maximum Travel Speed: 4.000 in/s (102 mm/s)
* Motor Drive: Stepper Motor Size: 23
