Ab dick 9910 xcs + ae swing-away + kompac + powdair 3
* 'New' Style Kompac Dampening System
* Anniversary Edition Townsend T-51 Swing-Away!
* 'Adjust on the Fly' Second Color Head!
* POWDAIR 3 Powder Drying System
* Condition: This press is in good condition throughout. It is very clean and working very well. It will make the new owner very happy!
* This press has been print tested and registered by an AB Dick Trained Technician.
* AB DICK 9910 XCS Two Color Offset Press Delivers Great Control and Convenience.
The AB DICK 9910 XCS is designed with easy operation in mind. With the ability to use polyester or metal plates and print full-bleed 11x17", it handles a wide range of small-lot jobs with superb efficiency.
* KOMPAC Dampener 'NEW-STYLE': Obviously an amazing dampening system. This is the newest style of KOMPAC from VARN. It is coverless and has the 'KOLORMATE' option (extra oscillator) More features / benefits outlined below. *New Cost: $3,500*
* Anniversary Edition Townsend T-51 Second Color Head: The T-51 AE Second Color head from Townsend incorporates: Ductor Shut-Off, Ink Roller clean up attachment, Cylinder separation, Continuous Dampener and On-The-Fly horizontal and vertical adjustments! *New Cost: $7500*
* Powdair 3: This is Powdair's top of the line powder spray unit. Features / Benefits outlined below. *New Cost: $1,400*
* AB DICK 9910 XCS Printing Press:
* Microlateral Paper Guide
* Electronic Preset/Reset Counter
* Feed On/Off Delivery Area
* Disengaging Hand Wheel
* Chain Delivery/Receding Stacker
* Paper Timing Release on Chain Delivery
* The KOMPAC is a completely automatic continuous dampening system.
* The KOMPAC delivers a carefully metered, thinner film of dampening solution to the plate.
* This film is AUTOMATICALLY adjusted and only the ink keys need be adjusted to maintain denser solids and sharper halftones.-
* AE Swing-Away TOWNSEND T-51 2nd Color Head:
* With the T-51 you can produce two-color work, with precise register, with one pass through the press. There is no need to wait for the first color to dry before running the second one. There is no second-color register waste & two-color production is nearly doubled! Four-color processes can be produced in just two passes! You can print single-color on your offset press by simply disengaging the T-51. The T-51 one can then standby until your next run. If that isn't satisfying, you can print single-color with the T-51! Takes up no more floor space than your offset press. Applications include: business cards, letterheads, envelopes, two-color thermography, duo-tones and/or all your two-color & four color work. Uses all the same inks, fountain solutions, plates & other printing supplies as your current press. Operating controls are similar to your current press to reduce operator training time. Greater operating economy & efficiency plus increased versatility.
* Townsend innovation & dependability.
* Impression triggered compressor shut off. Anti-static spray bar design Adjustable powder concentration. Auto speed sensing automatically adjusts Test mode to set powder concentration. Spray to changes in press speed. Pulsed spray timed to sheet.
* Air blow down for improved sheet delivery.
* Maximum Paper Size: 13.39" x 17.72" (340 x 450 mm)
* Minimum Paper Size: 3.54" x 5.12" (90 x 130 mm)
* Maximum Printing Area: 13" x 17.24" (330 x 438 mm)
* Paper Thickness: 0.0016" ~ 0.012" (0.04 ~ 0.3 mm)
* Printing Speed: 3,000 ~ 10,000 iph
* Maximum Plate Size: 13.19" x 19.37" (335 x 492 mm)
* Metal Plate Type: Pin bar / straight edge; 25 holes, 0.5" (12.7 mm) pitch
* Feeding System: Universal feeder
* Feeder Pile Capacity: 17.72" (450 mm)
* Delivery Pile Capacity: 20.47" (520 mm)
* Ink rollers: 10 (2 form rollers)
* Water rollers: 5 (1 form roller)
* Gripper Margin: 0.315" (8mm)
* Vertical Image Adj.: 0.787" ( 20 mm)
