New port m-UMR5.16 precision linear stage
Newport M-UMR5.16 Precision Double-Row Ball-Bearing Linear Stage
The Newport M-UMR5.16 Precision Double-Row Ball-Bearing Linear Stage is the metric version of Newport's UMR series, made for them by Micro-Controle. All-Steel construction, with a double row of ball-bearings on each side which increases the load carrying capacity of the stage to an amazing 135 pounds! This stage is capable of maintaining an angular deviation of less than 200 micro-radians. These can be stacked into an X/Y configuration, or can be made into an XYZ stage with a EQ angle bracket. It is also compatible with UTR and UTM Rotation Stages, BGM Goniometers, and SL Mirror Mounts. The top surface is tapped and threaded with several patterns of holes in M3, M4, and M6 threads. The stage measures 2.28 inches long, by 1.97 inches wide and is .51 inches tall. Accepts threaded actuators, BM11.16, DM11-16 or the FP3-5 Fixed positioning kit. Actuator not included.
