> Display technologies 7" monochrome crt kit V14050-100E
Display technologies 7" monochrome crt kit V14050-100E
DISPLAY TECHNOLOGIES V14050-100E 7" MONOCHROME CRT KIT
31.5 kHZ - 12 VDC - P4 PHOSPHOR
This Model is a 7 monochrome (P4AG) operating at 31.5k Hz, or what is typically referred to as VGA. The frequency range is 30 to 33.5k Hz. The signal is analog (.700V nominal) with separate H and V sync at 2.75V nominal. Signal and power is through a 2x10 shrouded header. The 2x10 rows are redundantly connected. The pin connections are as follows.
Pin 5. Remote Brightness (wiper)
NEW - OLD STOCK - DATE CODE 1994
CRT - CLINTON 678KAMGAG - DISPLAY TECH P/N 9602505D21
YOKE - ZEMINTRON LTD. TYPE 90912 - DISPLAY TECH P/N 2429662A01
FLYBACK - SAMPO FDA137 - DISPLAY TECH P/N 2529669B01
