Harvard apparatus phd-2000 hpsi syringe pump 70-2023
HARVARD APPARATUS PHD-2000 HPSI SYRINGE PUMP 70-2023
Harvard Apparatus PHD-2000 Programmable HPSI (High Volume + Pressure) Syringe Pump
Includes: Remote Extension Cable, 5 Ft/1.5m, Model: BS4-72-0199
High capacity up to 800 ml with four 200 ml syringes
Ultra high pressure provides over 400 lbs of pumping force
Programmable advanced capabilities with programming
Built to last rugged construction for a lifetime of service
Type Microprocessor driven syringe pump
Syringes (Min/Max) Holds 20 to 200 ml stainless steel syringes
Non Volatile Memory Stores all settings
TTL 9 pin D-Sub. Connector
Average Linear Force 433 lbs
Drive Motor 1.8 stepper motor, geared 1:10
Motor Drive Control Microprocessor controlled from 1/2 to 1/32 microstepping
Motor Steps per one From 8,000 to 128,000
Voltage Range 95 to 130 VAC, 60 Hz; 220 to 260 VAC, 50 Hz, selectable
Cable Length 152 cm (60 in) approx.
Control Box 9.5 x 27.9 x 22.9 cm (3.75 x 11 x 9 in)
Syringe Holder 22.9 x 43.2 x 30.5 cm (9 x 17 x 12 in)
