Gelcoat spray gun - G660 4.5 resin & gel coat spray gun
This is our newest Gravity Feed production spray gun used specifically for Gel Coat & Polyester based Resin systems. The G660-4.5 main features are a large 1-liter plastic container to hold plenty of Gel Coat or Resin so more spraying is accomplished with less filling. And a Gel Coat & Resin Specific 4.55 mm nozzle so you can rapidly spray any size parts with ease. Whether you are using this gun for high production parts or just making a few parts a month, this Spray Gun is designed for low maintenance and has the durability needed for everyday use. It is light weight, user friendly and has little or no material waste. The spray quality is excellent and it is extremely versatile and mobile. High surface coverage combined with a 1 liter cup make this gun the perfect addition for composite shops of all sizes.
Consumption CFM is 7-12: Feed Type is Gravity: Pattern Width of Fan Shape at 180 mm: Air Pressure is 50 to 80 psi: Rated Pressure 70 psi: Output is 300 gm/min: This our Item# G660-4.5 and if you have any questions please feel free to call (***)-992-2331 Infinity FRP Supply..
Like all our other spray guns this gun is a real work horse and a great fit for any fiberglass shop.
Even though this gun is made to last, replacement parts are available if ever needed so just call or email Infinity FRP Supply.
This from the manufacturer: The 660 is not classified as a HVLP gun because it has higher air volume. Having higher air volume does tend to make the G660 a much better gun for higher production shops. The higher volume air allows for a larger nozzle (4.5mm) and still achieve proper atomization.
The manufactuer has noted: We have yet to sell any replacement parts - excluding the plastic cup - for the G660. These are shaping up to be bullet-proof!
Instruciones de Funcionamiento
The Portaspray Gelcoat Gun is simple and easy to use, for spraying gelcoat and resins
La Pistola Polyspray/Portaspray de gel es simple y facil de usar para rociar capas de gel y resina
Ensure main in-coming air compressor supply should be preferably 50-80psi (7-12 CFM)
Asegura la fuente entrante principal del compresor de aire debe ser preferiblemente 50-80psi (7-12 CFM)
The (Top Bottom Valve) must initially be closed.
La necesidad (de la v lvula inferior superior) sea inicialmente cerrada.
Connect the air compressor air hose fitting to the Air Supply Valve
Conecte la manguera de aire del compressor de aire que cabe con la v vula de suministros de aire.
Pour material (pre-mixed spray grade gelcoat and catalyst into the plastic container/cup.
Echar el material (gelcoat y catalizador premezclados del grado del aerosol en el envase pl stico o taza
Depress trigger and open/adjust the Material Feed Flow Valve (Centre Valve) normally about 10mm in length
open/anti-clockwise position until the material flow out smoothly.
Precisione el disparador y abra el ajuste de valvula de Aujo material de la alimentacion (v vula) del centro normalmente cerca
de 10mm en la posici n de /anti-clockwise de la longitud hasta el flujo material hacia fuera suavemente.
Adjust Air Pressure Atomiser Valve (Bottom Valve) until the material is fully atomized to a round spray pattern
Ajuste la v lvula del atomizador de la preci n de Aire (v lvula inferior) hasta que los materiales se atomizan completamente a
Then adjust the Flat Spray Pattern Adjuster Valve (Top Valve) to a flat spray pattern about 5- 10psi
Entonces ajuste la valvila plana del ajustador del aerosol (valvula superior) a un patron de aerosol piano sobre 5-10psi.
When finished spraying, discharge remaining material by compressing trigger, add more
acetone to rinse and clean container and spray out accordingly.
Cuando la rociadora acada, descarga el material restante comprimiendo disparador, agregue m s acetona a la aclaraci n y limpie el envase y
el aerosol hacia fuera por comsuguiente.
Again pour clean acetone into container and discharge acetone bt depressing trigger so as to
clean the internal of the gun and nozzle. Repeat 3-4 times as deems necessary.
Echar la acetona limpia en el envase y descargue otravez, el disparador que preciona del bt de la acetona para limpiar el
interior del arma y del inyectir. repita 3-4 veces como juzge necesario.
Remove nozzle cap and clean with acetone using brush.
Quite el casquillo del inyector y limpie con la acetona usando el cepillo.
Consumo CFM 7-12: Tipo de alimento Gravity: Anchura de patron de la forma del ventilador 180 mm: Precission de Aire 50 - 80 psi: Precission sometida 70 psi: Informacion 300 gm/min: Talla de boquilla 4.5 mm
