Agilent hp 5372A frequency & time interval analyzer
Agilent HP 5372A Frequency & Time Interval Analyzer
The Agilent 5372A modulation domain analyzer captures frequency, phase, or time intervals at extremely high speeds.
The 5372A can make up to 13.3 million measurements per second for signals with a frequency range of up to 500 MHz. An optional channel expands the range to 2 GHz.
The 5372A combines a choice of over 60 arming and triggering configurations with built-in analysis functions including math, statistics, and limit testing.
Unique to the 5372A (compared with the 5371A) are deeper memory, hardware histograms, and FFT capabilities for high-performance and more sophisticated jitter spectrum analysis and phase noise studies.
The 5372A lets you: analyze jitter effects, characterize the transient and steady state responses of a VCO, examine frequency or phase modulation, measure frequency stability, analyze computer peripherals, or measure fast hopping radio signals.
Broad selection of measurements :
Quick and easy-to-use push button analysis
Characterize frequency, phase, and time-interval versus time
Graphic display and histograms for added visual meaning from collected data
200 ps single-shot, Least Significant Digit (LSD),
10 digits/second for frequency measurements (2 ps LSD for averaged measurements)
go to: http://www.home.agilent.com/upload/cmc_upload/All/EPSG084794.PDF
The Agilent / HP 5372A analyzer is used, good working condition.
Cosmetically it could be estimated as 8 from 10 some scratches could be finding all over chassis.
Puled out from working environment.
Nothing more is added or promised.
