Hp agilent 71500A microwave transition analyzer
HP Agilent 71500A Microwave Transition Analyzer
The 71500A Microwave Transition Analyzer is a two-channel sampler-based time-domain instrument for making stimulus-response measurements from dc to 40GHz. It is ideal for characterizing components and systems in a benchtop environment. You can measure rise and fall times, time delay, peak and average power, group delay, AM to PM conversion, and much, much more. All functions of the 71500A are programmable. In addition, custom application-specific interfaces can be developed for Agilent Instrument BASIC and run internally. This use of IBASIC eliminates the need for an external controller in many applications.
* Non-linear component testing dc to 40 GHz
* Two channels Measurements Phase settling Rise/fall times
* On/off ratios Delay Switching time Peak/average power
* Group delay Performance 1 ps delta t accuracy Trigger to 40 GHz 10 ps rise time
