Tektronix 1740 waveform monitor / vectroscope
Tektronix 1740 Waveform Monitor / Vectroscope
The Tektronix 1740 is an NTSC format Waveform/Vector Monitor combining all the basic waveform monitoring and vectorscope functions into a single, compact half-rack package.
Composite waveform monitoring,
Time code phasing and amplitude,
SCH and color framing display Vector,
Lightning, Diamond and Bowtie.
Composite or Component Waveform Monitoring:
Menu-Assisted Operation allows expanded feature set
Assignable cursors for time and voltage
Picture monitor mode for verifying signal source
Longitudinal time code display mode for editing applications
External staircase from a camera control unit can be selected remotely
Internal video filters provide specialized measurements, with dual or triple filter modes available in PARADE or OVERLAY
Eight video inputs can be individually displayed or selected in various combinations
Remote interface and serial RS232 interface
90-132/200-250 Vac; 48-66 Hz operation
Size: 133 mm (5.25 in)H x 216 mm (8.5 in)W x 460 mm (18.1 in)D
Cosmetically is estimated as 7 form 10.
This Tektronix 1740 vectriscope/ waveform monitor is powering on.
The traces are adjusted at vertical and horisontal position.
The scale function is not working- the changing of the lamps could solve the problem.
No other tests has been performed.
