1972 tachella 612UA 10" x 24" universal id/od grinder
1972 TACHELLA 612UA 10" x 24" UNIVERSAL ID/OD GRINDER
10" X 24" TACCHELLA "ITALIAN" PRECISION
(ORIGINALLY IMPORTED BY WARNER & SWASEY)
MODEL: 612UA S/N: 3580 NEW: 1972
MAXIMUM SWING OVER TABLE............... 10"
DISTANCE BETWEEN CENTERS............... 24"
TRAVERSE SPEED......................... 4" TO 276" I.P.M.
SWIVEL TABLE GRADUATED (DEG. INCLUDED
ANGLE)................................. 10 DEGREES
GRINDING WHEEL ........................ 14" DIA.
SWIVEL RANGE .......................... +/- 90 DEGREES
(2) GRINDING WHEEL SPINDLE SPEEDS...... 1640/1900 R.P.M.
INFEED HANDWHEEL, 1 GRAD. = ........... 0.0002"
AUTOMATIC INFEED @ TABLE REVERSAL,
ON DIA. .............................. 0.0005" TO .002"
PLUNGE GRINDING, FEED RATE RANGE ...... 0.0005" TO .070"
MIN./MAX. PLUNGE CUT DEPTH ............ 0.004" TO .16"
RAPID HYDRAULIC INFEED STROKE.......... 1- 1/2"
INFINITELY VARIABLE WORKHEAD SPEEDS ... 30 TO 600 RPM
WORKHEAD TAPER......................... #3 MT
DIA. OF HOLE, WORKHEAD SPINDLE......... 1- 7/16"
WORKHEAD SWIVEL RANGE.................. +/- 90 DEGREES
TAILSTOCK TAPER........................ #3 MT
TAILSTOCK STROKE ...................... 3/4"
APPROX. DIMENSIONS .................... 64" X 60" X 70"H
APPROX. WEIGHT ........................ 5,200 LBS.
SWING DOWN INTERNAL GRINDING ATTACHMENT w/SPINDLE
WHEEL BALANCING STAND WITH ARBORS
-SINGLE LEVER AUTO CYCLE CONTROL
-DUAL RATE (COARSE & FINE) PLUNGE INFEED
-RAPID WHEELHEAD AVANCE & RETRACTION
SPARKOUT TIMER (0 TO 60 SECONDS)
14" x 2"W GRINDING WHEEL PRESENTLY ON MACHINE
INFINITELY VARIABLE ELECTRONIC SPEED CONTROL FOR WORKHEAD
MOTORS ON MACHINE ARE DUAL VOLTAGE (220/440 VOLTS)
ITALIAN BUILT MACHINE, SUPERIOR QUALITY! **
