Fluke 5820A-5C-ghz 5 ch 2.1 ghz oscilloscope calibrator
Fluke 5820A-5C-GHz 5 Ch 2.1 GHz Oscilloscope Calibrator
Retiring one our oscilloscope laboratory standards.
Calibration Due November 2010.
Includes NIST traceable certificate of cal.
The powerful 5820A Oscilloscope Calibrator is a complete, yet flexible solution for oscilloscope calibration. It calibrates virtually all your digital and analog oscilloscopes quickly, easily and affordably. With its high bandwidth option (GHZ), the 5820A's performance can calibrate oscilloscopes up to 2.1 GHz. And the 5820A's five-channel output option facilitates fast, hand-free automated calibrations.
* Option 5C-GHZ = 2.1 GHz Oscilloscope Calibrator, Five Channel
5820A Mainframe Specifications *
Best 1 Year Specification: 0.25%
Best 1 Year Specification: 0.025%
Range: 1 mV to 6.6V p-p (50W)
Range: 1 mV to 130V p-p (1 MW)
Best 1 Year Specification: 0.05%
Best 1 Year Specification (standard mainframe):
Best 1 Year Specification (with option):
Range: 50 kHz to 2.1 GHz (with option)
Best 1 Year Specification (with 5820A-GHz):
Spike, square, 20% pulse, sine
Best 1 Year Specification: 3% Amplitude
Range: 15 mV to 1.5V amplitude
Best 1 Year Specification: 5%
Best 1 Year Specification: 0.33 ppm
Best 1 Year Specification: 0.05%
Best 1 Year Specification: 0.25%
Best 1 Year Specification: 0.1%
Best 1 Year Specification: 5%
Height: 17.8 cm (7 in), standard rack increment, plus 1.5 cm (0.6 in) for feet on bottom of unit
Width: 43.2 cm (17 in), standard rack width
Depth: 47.3 cm (18.6 in) overall
