> MSO7102T 100MHZ digital oscilloscope logic analyzer 1G
MSO7102T 100MHZ digital oscilloscope logic analyzer 1G
Portable OSCILLOSCOPE 100MHz MSO7102T logic analyzer 1G
25MHz 100MHz Bandwidth, up to 500MS/s real time sample rate
Advanced trigger functions: Edge trigger, Bus
trigger, Pattern trigger,Sequential queue trigger,
Distributed queue trigger and Data width trigger.
7.8 inch color LCD, 256 colors, STN/TFT screen, 640 480 pixels
5ns/div-5s/div step by 1-2.5-5
5ns/div-100s/div step by 1-2-5
8 bits resolution (2CH simultaneously)
300V(DC+ AC Peak) (1M input impedance,Probe Attenuation rate 10:1)
1M 2% in parallel with 15pF 3pF
Edge Video Alternate Mains supply
Vpp,Vavg,RMS,Frequency,Period,Vmax,Vmin,Vtop,Vbase,Width, Overshoot,
Edge trigger, Bus trigger, State trigger, Data alignment trigger, Data width trigger
Current electronic products have become more complicated as the number of digital circuits and USB applications have increased. As a result, the cutting edge of measurement technology
has become vague and it is now difficult to choose a suitable testing instrument. Test signals are often mixed analog and digital signals, and engineers would like to have an instrument that can
test both analog and digital signals. Our MSO series was launched to meet these demands.
-MSO series Mixed LA-oscilloscope
The MSO series combines digital storage oscilloscope & logic analyzer functions with powerful features and remarkable performance. Our MSO series enables powerful analysis of both analog
and digital signals from a single cost effective test instrument.
Up to 100Mhz bandwidth, up to 500MS/s Sample rate (Real-time)
Advanced trigger functions: Edge trigger, Video trigger and Alternate trigger, Mains supply trigger.
20S/s 400MS/s Sample rate (step by 1-2-5)
Support USB data transmission and U-storage.
2 in 1 Test and Measurement Instrument
, users can view, trigger and analyze two types of signals on one instrument.
Powerful Test and Measuring Functions
OWON MSO's have powerful test and analysis functions, which include Multi-trigger functions, Bus setting, Threshold Level adjustment setting, Data searching, Digital filter, Save and recall trigger setting, Auto bus measuring, Cursor measuring, Pre-trigger setting, Code Setting, USB storage, and more. The OWON MSO series has functions written specifically for TTL and CMOS logic families. This allows it to analyze the most common digital circuits fast which saves R&D time.
Capture and Analysis of Signal Glitches
The time sequence waveform generated in a digital circuit is commonly disrupted by glitches. A single purpose logic analyzer can not measure the shape of a glitch but only analyze high and low levels. Thus, an engineer needs an oscilloscope in addition to a logic analyzer to accurately identify
Complementary Functions Improve the Measurement Accuracy
Waveforms from a logical analyzer are obtained by comparison between a test signal and threshold level. An incorrect threshold level would lead to confusion for the entire test sequence. The OWON MSO can help the user understand the time sequence information exactly so that the threshold Level can be set correctly.
The control panel of the MSO5022 and MSO7102 use OWON's standard layout which is familiar to many users, so current users can save time and intuitively learn the functions of this new product.
With our competitive pricing of the MSO5022 and MSO7102, they can be widely used in schools
and institutions for electronics education including digital circuit analysis. This was the case for
3.To trigger the high and low level models on several wires at the same time and examine the results
4. To trace the execution of software in the system timely.
1. Electronic circuits, communication, optoelectronics, etc.
2. R&D, design, and debugging of digital circuits.
3. Education and training in the field of digital circuits and signals.
With advanced digital sampling technology,users can detect and debug signals from two channels simultaneously. Real-time sampling allows for the capture of unrepeatable signals such as glitches,
complex edge details, or other high frequency signal components. This allows engineers to identify
and control many obscure signal changes.
High Precision Sampling Technology
The MSO series utilizes very precise sampling technology to simultaneously collect 16 test signals. The user is in control of the graphical display of each signal so that an engineer can easily analyze signals of interest.
Strong trigger functions enable a user to detect time sequences reliability and accurately by many
methods. As a tool of logic analysis, trigger function performance decides the practicality of the
instrument.The MSO series incorporates many trigger functions including Edge trigger, Bus trigger
,Pattern trigger, Sequential queue trigger,Distributed queue trigger,and Data width trigger.
Flexible Setting of Trigger Position
An unexpected event or bug in a digital circuit often happens at a certain moment,and the analysis
should be based on signal changes before and after that moment. Since,the trigger points for the
MSO5022 and MSO7102 are adjustable, an engineer is able to observe the time sequence before
and after the triggered event and point-analyze the specific data queue timely and effectively.
Bus Functions Help Analyze Time Sequences Quickly and Effectively
To analyze logical time sequences, signals are often collected from many channels which results
in too many data channels being shown on the screen.This makes the data very hard to analyze.
For example,an address bus or data bus is composed of multidigit data,and choosing some of the
channels as one independent bus significantly reduces the number of channels viewed together.
The threshold signal as a standard for the high and low level of a digital signal can determine the
accuracy of a whole measurement. Our MSO series offers threshold settings ranging from 0 to 4V and includes many independent threshold settings to meet many particular testing conditions.
Trigger position and the analysis of a certain pattern are the keys to debugging logical circuits,and
how to lock the trigger position quickly or search the expected bus patterns are the foundations
of improving debugging efficiency. Our MSO series supplies search modes such as trigger position,
bus pattern, and state settings to locate the time sequences quickly and exactly.
The random of noise or glitch in the digital circuit can effect the analysis of the whole waveform or change the time sequence result. Our digital filter function is able to inhibit the burrs effecti-
vely when the signals change on the bus, and make the waveform clear to be analyzed.
For a complicated circuit, it is essential to set different triggers to analyze a time sequence, and
the same trigger setting usually must be used repeatedly. If we reset the trigger condition,much
time and energy will lost.That s not a problem for our MSO series,because we can save the trigger
settings, and the repeatable trigger is available for recall after saving.
