Boc edwards IQDP80/QMB1200 dry pump/blower package
BOC Edwards iQDP80 Dry Pump & QMB1200 Mechanical Booster Package
The Main Serial Number Tag Reads:
Model Number: 2xIQDP40/IQDP80-QMB-1200 (There is no iQDP40s in this rack)
Power Requirements: 208 V, 3 Phase, 60 Hz, 19.1 FLA
The Power Requirements Tag Reads:
Supply Voltage / Phase / Frequency: 208 V, 3 Phase, 60 Hz
Largest Motor Ampere Rating: 16 A
Main CB Short Circuit Interrupt Capacity: 2000,000 AIC
The Pump's Serial Number Tag Reads:
Max. Continuous Inlet Pressure: 0.75 Torr
Max. Water Consumption: 246 l/h
Operation Temperature: 131 F to 194 F
Coolant/Water Capacity: 1.7 liters
Oil Capacity - Coupling Cover: 2.4 liters
Oil Capacity - Shaft Seal: 0.125 liters
Oil Capacity - Gear Case: 1.65 liters
Type PFPE Perfluoropolyether: Fomblin Y25 Krytox 1525, Fomblin YVAC 16/6 Krytox 1514
Vacuum Bearing Grease PFPE: Fomblin RT15
Common Motor Voltage: 208 / 460 VAC
Nitrogen Purge Supply Pressure: 20 to 100 psi
Dimensions: 44.52" L x 20.52" W x 41.3" H
