Model engineering - how to book
A Guide to Model Workshop Practice
With Working Drawings of Engines,
Boilers, Rolling Stock, Cannon,
Originally published in 1915. This book is the work of a thoroughly practical engineer possessing unequalled experience of model making, and it is addressed to the amateur desirous of learning how mechanical models, chiefly prime movers, operate and how they can be made in the home workshop. It fully describes the tool equipment necessary, shows how to use the tools and how to execute the numerous handcraft processes involved, and then enters into the details of steam, petrol and electric models; it shows the function of various parts, and explains, step-by-step, the actual amateur workshop methods of building them up, the reader being taken easily and gradually through the construction of every part and the assembling of the complete models, these including boilers, steam engines, internal-combustion engines, steam locomotives, electric locomotives, permanent ways, power hammers, cannon, etc., etc.
* The equipment of a model engineer s workshop
* The lathe and its fitments
* The various processes involves
* Model steam-engine cylinders
* Types of model steam-engine cylinders
* Engine cranks, connecting rods, bearings, and eccentrics
* Steam-engine valves and reversing gears
* Model boiler design and construction
* Model boiler and engines valves and fittings
* Force pumps, injectors and gauges
* Historical and other scale Glass-case models
* Making a model 1-in. by 1-in. vertical steam engine
* A high-speed compound condensing engine and coil boiler
* A -in. scale model Midland Railway Express Locomotive
* A working model Metropolitan Railway Electric Locomotive
* Internal combustion engines
* Miscellaneous working models
* Model G. C. R. Express Locomotive
