> New moxa awk-1100-us AWK1100 access point bridge client
New moxa awk-1100-us AWK1100 access point bridge client
Industrial IEEE 802.11g/b wireless Access Point/Bridge/AP Client
WLAN Standards: IEEE 802.11g/b for Wireless LAN, IEEE 802.3u 10/100BaseT(X) for Ethernet LAN, IEEE 802.3af for Power-over-Ethernet; Frequency Range: 2.4-2.4835 GHz, Direct Sequence Spread Spectrum (DSSS); Data Rate & Modulation: OFDM @ 54 Mbps, CCK @ 11/5.5 Mbps, DQPSK @ 2 Mbps, and DBSK @ 1 Mbps; Operating Channels: USA: 1-11 (US), Europe: 1-13 (EU), Japan: 1-14 (JP); Security: 64-bit and 128-bit WEP encryption, WPA (IEEE 802.1X/RADIUS and TKIP); Data Rates: 1 Mpbs, 2 Mbps, 5.5 Mbps, 6 Mbps, 9 Mbps, 11 Mbps, 12 Mbps, 18 Mbps, 24 Mbps, 36 Mbps, 48 Mbps, 54 Mbps; Transmit Power: Typ. +18 dBm (+/- 1.5 dBm) @ 11 Mbps, +14 dBm (+/- 1.5 dBm) @ 54 Mbps; RX Sensitivity: 802.11b: -81 dBm @ 11 Mbps, -85 dBm @ 5.5 Mbps, -86 dBm @ 2 Mbps, -87 dBm @ 1 Mbps; 802.11g: -68 dBm @ 54 Mbps, -70 dBm @ 48 Mbps, -74 dBm @ 36 Mbps, -78 dBm @ 24 Mbps, -81 dBm @ 18 Mbps, -84 dBm @ 12 Mbps, -85 dBm @ 9 Mbps, -86 dBm @ 6 Mbps; Software Protocols: HTTP, DHCP, TCP/IP, RADIUS; Confi guration: Web-based management; Client OS Support: Windows (95, 98, 2000, ME, NT, XP), Unix, Macintosh; Interface Antenna: 2 dBi omni-directional antenna with an RP-SMA connector, RJ45 Port: 10/100BaseT(X) auto negotiation speed; Power Requirements Input Voltage: 12 to 45 VDC, redundant dual DC power inputs or 48 VDC Power-over-Ethernet (IEEE802.3af); Power Consumption: 0.3 A @ 24 V; Overload Current Protection: 1.6 A; Connection: Removable terminal block; Reverse Polarity Protection; Physical Characteristics Housing: metal, providing IP30 protection, Dimensions: 53.6 x 135 x 105 mm (2.11 x 5.31 x 4.13 in.), Weight: 800 g, Installation: DIN-Rail mounting, wall mounting (optional kit). Environmental Limits Operating Temperature: 0 to 60 C (32 to 140 F).
The AWK-1100 is rated to operate at temperatures ranging from 0 to 60 C and is rugged enough for any harsh industrial environment. Installation is easy, with either DIN-Rail mounting or distribution boxes. The DIN-Rail mounting ability, wide operating temperature range, and IP30 housing with LED indicators make the AWK-1100 a convenient yet reliable solution for any industrial wireless application.
One New Moxa AWK-1100-US, Industrial IEEE 802.11g/b wireless Access Point/Bridge/AP Client.
