> 4"X3" FR4 prototype pcb propeller pic avr stamp micro
4"X3" FR4 prototype pcb propeller pic avr stamp micro
Introducing Proteus - a new prototyping board.
While Proteus does have MORPHBUS, EXP1 and EXP2 headers so that you can add it to a Morpheus system, it is entirely usable on its own, or in conjunction with any other 4 x3.05 Parallax mounting pattern prototyping board - for example ProtoBoard, ProtoBoard USB, SX, Stamp and other boards.
Look at the JPEG image below to see the top of the board.
* Unique layout to optimize 0.3 and 0.6 dip spacing
* Interleaved zig-zag Vcc/Gnd bus
* single row header support on the bottom of the board
* easy to configure for servo headers
* easy to mount 2 5 (or 2xN) headers
* area for voltage regulation above MORPHBUS header
