20" y 40" x hansvedt sm-18 cintrojet ram-type edm, 150
20" Y 40" X Hansvedt SM-18 CINTROJET RAM-TYPE EDM, 150
20" Y Axis 40" X Axis Hansvedt SM-18 CINTROJET RAM-TYPE EDM, 150 AMP, DRO, BIG CAPACITY, 60" x 30" W
HANSVEDT "VERY LARGE CAPACITY" RAM TYPE EDM
MODEL: CINTROJET 18E S/N: J12101 NEW: 06/1992
WORK TABLE SIZE ...................... 41" x 25- 1/2"
LONGITUDINAL TABLE TRAVEL ............ 40"
CROSS TRAVEL ......................... 20"
WORTANK SIZE (INSIDE DIMS.) .......... 60" x 30" x 18"H
PLATEN TO TABLE ...................... 11" MAX., 23" MIN.
RAM TRAVEL ........................... 12"
MAX. WEIGHT ON PLATEN ................ 1,650 LBS.
MAX. WORKPIECE WEIGHT ON TABLE ....... 4,000 LBS.
DIELECTRIC RESEVOIR (MACHINE BASE).... 210 GALS.
APPROX. WEIGHT ....................... 10,700 LBS.
APPROX. DIMS. ........................ 116" x 114" x 93"H
HANSVEDT "H-PULSE" MODEL #1506 150 AMP POWER SUPPLY
"FUTABA" 3-AXIS DIGITAL READOUT DISPLY
MACHINE IS WIRED FOR 3/60/440 VOLTS
PARTS & SERVICE AVAILABLE FROM THE "OEM":
