Sony xc-75 monochrome camera module ccd with flash
Sony XC-75 Monochrome Camera Module CCD with Flash
Description of SONY XC 75: The XC-75 series of monochrome camera module has been designed to be a more compact and versatile version of the widely used XC-77 for machine vision application. The XC-75 has an asynchronous trigger shutter function (S-DONPISHA) that allows fast moving objects to be captured upon the application of an external signal. The XC-75 series has been made even more versatile by the introduction of the L-type frame. This enables installation systems where space is a premium without using a mirror.
* High Resolution : 570(H) x 485(V) TV lines
* High Sensitivity, High S/N ratio
* Electronic Shutter (1/ 125 ~ 1/ 10,000 sec.)
* Asynchronous Shutter (S-DONPISHA)
* External Shutter Speed Control (0.8V ~ 1/ 500,000 sec.)
* Interlaced/ Non-Interlaced
* Picture elements 768(H) x 494(V)
* CCD horizontal frequency 14.318MHz
* Cell size 6.35(H) x 7.4 (V) micron m
* Flange Back 17.526mm 0.05
