Tektronix 11A34 service & user manuals (2)
Very high resolution, reproduction grade, 2 manual set on CD-ROM
for the Tektronix 11A34 FOUR CHANNEL AMPLIFIER PLUG-IN for the
THESE SCANS ARE BOOKMARKED IN GREAT DETAIL
ALL ELECTRONIC PAGE NUMBERS MATCH THE ORIGINAL MANUAL PAGE NUMBERS
(i.e. 2-1,2-2,2-3, etc. NO MORE GUESSING WHERE YOU ARE)
Tektronix 11A34 USERS REFERENCE SUPPLEMENT: This volume covers; Detailed Operating Instructions for use in the 11300 and 11400 series of oscilloscopes. Comprises 51-pages in a 2-MB PDF file, Reproduction grade high resolution scan of Tektronix part # 070-5921-01
Tektronix 11A34 SERVICE REFERENCE:
This volume covers Check-out, Maintenance, Calibration, Theory of Operation, Troubleshooting, Field
Replaceable Parts lists and Exploded Mechanical Views. P/N 070-6785-02, 101-pages in 3-MB in PDF file format.
(Sorry , there are NO BOARD LEVEL SCHEMATICS)
Text with photos: 600dpi, grayscale (contrast adjusted) Text with Drawings: 600dpi black and white
