Usb motion controller 4AXIS stepper motor cnc
JAF Solar 4 Axis USB Stepper Controller
Installation can be done in under 15mins!
JAF Motion Solar4x Motion Controller
* USB Interface, Drivers available for Windows, Mac and Linux. Emulates a serial port for easy programming.
* Plug in upto 4 JAF MicroStep Modules (3 MODULES INCLUDED. See below for details)
The controller has an USB interface, this allows the controller to be operated by an PC with a USB port.
The controller command language is in a plain ASCII format so can be simply controlled from many operating systems.
All the complex stepper motor drive functions are built into the controller, the allows even the very slowest of PC's to operate the controller.
Designed and Manufactured in the United Kingdom.
1 X JAF Solar 4 Axis USB Stepper Controller
3X JAF MicroStep Modules (Extras can be purchases separately)
JAF Server Software - Free Download
JAF Graphics....For a Fast and Friendly Service!
JAF Graphics Ltd, Unit 5 Thomas Street, Congleton, Cheshire CW12 1QU
Click here for JAF Solar Command Set.pdf
Click here for JAF Solar4X User Manual.pdf
Click here for MicroStep Module datasheet.pdf
PROJECTS USING OUR CONTROLLER.
Please email with any questions regarding your application.
Windows based control program, allows for easy control of a machine using our JAF Solar Controller.
Camera Interface for alignment / positioning of machine.
JAF Server Interface with camera view
JAF Server Interface with digitising panel
Datuming functions allow easy and accurate location of jigs etc.
Automatically execute CAM code saved to disk using third party machining software.
JAF Filters, convert many file formats on the fly, allows GCODE, HPGL, DXF etc., to be sent directly to the machine.
A selection of videos of various projects using our JAF Solar Controller.
Installation of JAF Solar4X Controller
* Stepper motors, Type 17 of Type 23 recommended
* Power Supply, laptop power supplies are ideal.
* A PC for the JAF Server software.
* A USB lead with a Mini-B connection, the sort you get this digital cameras.
Our stepper motor drives and motion controllers are all designed and manufactured by ourselves, his gives us the ability to produce custom designs to suit your requirments.
If you require a custom electronic/software design then please contact us to discuss your requirments.
Single & Multi Axis Motion Controllers
* Only 30x17.5mm, DIP24 Package Size
* Uses latest Allegro A3893 microstep control IC.
* upto 2A, 8 to 35V Drive Capabilities*
* Full, 1/2 , 1/4 or 1/8 step selectable
* 8 selectable drive currents
*2A drive current requires external resistor and improved heatsink/heat removal system for prolonged use. Without external resistor maximum current is 1.4A
* Designed and Manufactured in the United Kingdom.
